HASL 6Layers Electronic Circuit Assembly Contract PCB Assembly



Contract PCB Assembly Introduction



What is contract PCB assembly? Contract PCB assembly is when a contract manufacturer assembles the PCBs at their manufacturing facility for one particular customer. And they grow their business by getting additional contracts.



PCBA is for short, to mounted with components on PCB board and the manufacturing process. Only an advanced circuit board won't be able to give its functionality until components are mounted on it. These PCB boards require more design work than other wiring methods, but the assembly and manufacturing tend to be automated afterward. The automation makes PCB boards the cheapest and most efficient option.



PCB CAPABILITIES



FACTORY CAPABILITIES
No.	Items	2020
1	HDI Capabilities	HDI ELIC(5+2+5)
2	Max layer count	46L
3	Board Thickness	Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm
4	Min.Hole Size	Laser 0.05mm
		Mechnical 0.15
5	Min Line Width/Space	0.030mm/0.030mm
6	Copper Thickness	1/3oz-6oz
7	Size Max Panel size	700x610mm
8	Registration Accuracy	+/-0.05mm
9	Routing Accuracy	+/-0.05mm
10	Min.BGA PAD	0.125mm
11	Max Aspect Ratio	10:01
12	Bow and Twist	0.50%
13	Impedance Control Tolerance	+/-5%
14	Daily output	4,000m2 (Max capacity of equipment)
15	Surface Finishing	HASL Lead Free /ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD
16	Raw Material	FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI



PCBA CAPABILITIES

PCBA Capability
Material type	PCB			Components
Item	Dimension (Length, width,height. mm)	Material	Surface finish	Chip&IC	BGA Pitch	QFP Pitch
Min	50*40*0.38	FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC	HASL, OSP, Immersion gold, Flash Gold Finger	1005	0.3mm	0.3mm
Max	600*400*4.2





Our SMT capabilities:



SMT Assembly: SMT provides a flexible high technology.

These solutions include:

7 high-speed placement machines, 7 automatic printers with fiducial alignment, 2 X-ray machines, BGA maintenance machines, ICT test machines



Our DIP function:



A-8 semi-assembly production line with four wave soldering machines

1 U-shaped automatic assembly line for box-type building products with test stations

High temperature / low temperature aging test furnace B-4 for products required for aging test

With time control and temperature control

All products are 100% inspected and tested during the DIP process

Haina lean Electronics Co.,Ltd is a competitive China customize pcba for medical breathing machine OEM manufacturer, supplier and vendor, you can get quick turn customize pcba for medical breathing machine production prototypes and samples from our factory.

Hot Tags: customize pcba for medical breathing machine, China, supplier, manufacturer, factory, OEM manufacturer, vendor, samples, production, prototypes, quick turn



Electronic Board Assembly Process



1.Solder Paste stenciling
2.Surface Mount Technology (Pick and Place)
3.Reflow Soldering
4.Inspection and Quality Control
5.Through-Hole Component Insertion (DIP Process)
6.Final Inspection and Functional Test



Our advantage



Service value

Independent quotation system to quickly serve the market

PCB manufacturing

High-tech PCB and PCB assembly production line

Material purchasing

A team of experienced electronic component procurement engineers

SMT post soldering

Dust-free workshop, high-end SMT patch processing





Delivery Time





Electronic Board Assembly Application Field



Our products are widely used in communication equipment, industrial control, consumer electronics, medical equipment, aerospace, light-emitting diode lighting, automotive electronics.





Workshop



Partners





Common packaging

PCB: Vacuum packaging with carton box
PCBA: ESD packaging with carton box





Certification









FAQ



1.What are needed for quotation?
PCB: Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ......)
PCBA: PCB information, BOM, (Testing documents...)

2. What file formats do you accept for production?
Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)

3.Are my files safe?
Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third party.

4.MOQ?
There is no MOQ .We can flexibly handle small and mass production.

5.Shipping Cost ?

The shipping cost is determined by the destination ,weight ,packing size of the goods .We can provide shipping, air, land, express and other transportation services .

Q6.Whether all PCBA s will be tested before delivery ?

Yes , we will test each piece of PCBA product under your testing methods ,to ensure quality and functionality .

Q7.Do you provide OEM service ?

Yes ,we offer PCB and PCBA OEM Service , we manufacture the PCB and PCBA products to your design and requirements .
