HF FR4 Immersion Tin Contract PCB Assembly , SMT Thru Hole Assembly

HF FR4 Immersion Tin SMT & Thru-hole Contract PCB Assembly



Contract PCB Assembly Introduction





PCB assembly Including :

Components sourcing , PCB fabrication ,SMT ,DIP,Reflow soldering,Wave soldering,Hand soldering,Mixed assembly technologies,Cable assembly,PCBA testing,Final product assembly



Factory Capacity



Layers 1 - 46 L
Substrate FR-4,CTI600,Tg180,,Anti CAF,Halogen-free,,High frequency,Tg170&HF
Max. panel size 700x610mm
Board thickness 0.3 mm - 3.5 mm.
Copper thickness 1/3 oz. to 6 oz. (outer) (Max)
Hole > 0.15mm.
Aspect Ratio 10 : 1
Min. track width 3.0 mils(partial)
Min. track space 3.0mils(partial)
Min. S/M bridge 3mil
Hole plugging diameter 0.3 mm~0.55 mm.
Impedance tolerance +/- 10%.
Color of S/M green,white,black,red,orange,yellow,blue,purple
Surface treatment OSP,HAL,HAL LF,ENIG,Hard gold,Imm Ag,Imm Sn,Peelable soldermask,Carbon ink print,Selective hard gold



Our service



PCB Design & Layout
PCB Prototyping
PCB Fabrication
Turn Prototype PCB Assembly
PCB Assembly Services
PCB'A



HF FR4 Immersion Tin Contract PCB Assembly , SMT Thru Hole Assembly 0


Workshop & Equipment


AL-SPI-IA
solder paste printing equipment
wave-soldering
automatic printing equipment
60times magnifying glass
material baking equipment
X-ray welding inspection
Semi-automatic printing equipment
component counting equipment
Online AOI detector
Reflow welding equipment
Mydata welding equipment

HF FR4 Immersion Tin Contract PCB Assembly , SMT Thru Hole Assembly 1

HF FR4 Immersion Tin Contract PCB Assembly , SMT Thru Hole Assembly 2



Contract PCB Assembly Application


Aprospace ,Auto Industry ,Communication,Indutrial Control ,Medical device ,Smart Home.etc.

HF FR4 Immersion Tin Contract PCB Assembly , SMT Thru Hole Assembly 3


Common packaging


PCB: Vacuum packaging with carton box
PCBA: ESD packaging with carton box

HF FR4 Immersion Tin Contract PCB Assembly , SMT Thru Hole Assembly 4

FAQ

1, What service do you provide?
We provide turnkey solution including PCB fabrication, SMT Process, PCB Assembly,final assembly, Function testing and other value-added service.
2, What is needed for PCB & PCBA quotation?
PCB: Quantity, Gerber file and technic requirements(material,size, surface finish treatment, copper thickness,board thickness).
PCBA: PCB information, BOM,Testing documents.
3, How to keep our product information and design file secret ?
We can sign a NDA effect by customers side local law and promising to keep customers data in high confidential level.
4, What are the main products of your PCB/PCBA services?
Automotive, Medical, Industry Control,IOT,Smart Home,Military.
5, What is your minimum order quantity (MOQ)?
Our MOQ is 1 PCS, sample and mass production all can support.
6.What are the services you can provide ?
One-stop contract manufacturing
A:PCB Assembly;
B:PCB Design & Layout
C:PCBA programming & functional testing;
D:Electronic components purchasing service;
E:Enclosure molding & final assembly with labels,instructions,enclosure, boxes.
7.Whether all PCBA s will be tested before delivery ?
Yes , we will test each piece of PCBA product under your testing methods ,to ensure quality and functionality .
8.Do you provide OEM service ?
Yes ,we offer PCB and PCBA OEM Service , we manufacture the PCB and PCBA products to your design and requirements .
9. Do you accept process materials supplied by clients?
A Yes, we can provide component source, and we also accept component from client
