Low Dk HASL Lead Free Contract PCB Assembly , 2oz Surface Mount PCB Assembly
-
High Light
Lead Free Contract PCB Assembly
,Low Dk Contract PCB Assembly
,2oz surface mount PCB assembly
-
Product NameContract PCB Assembly
-
LayersMultilayer
-
MaterialFR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI
-
Surface TreatmentOSP,HAL,HAL LF,ENIG,Hard Gold,Imm Ag,Imm Sn,Peelable Soldermask,Carbon Ink Print,Selective Hard Gold
-
Copper Thickness0.3oz 0.6oz 1.0oz 2oz ...... 6oz
-
Min. Line Width & Spacing0.030mm
-
Board Thickness0.3mm-3.5mm
-
Min. Hole SizeLaser 0.05mm ; Mechnical 0.15
-
ApplicationConsumer Electronics,Industry/Medical/Consumer Electronic,PCBA Circuit Board
-
Solder Mask ColorGreen,white,black,red,orange,yellow,blue,purple
-
Place of OriginCHINA
-
Brand NameHNL-PCBA
-
CertificationISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000
-
Model NumberPCB Assembly
-
Minimum Order Quantity1 PC
-
PriceNegotiable
-
Packaging DetailsESD packaging with carton box
-
Delivery Time1-7days
-
Payment TermsT/T, Western Union, L/C, MoneyGram
-
Supply Ability10,000,000 Point /Day
Low Dk HASL Lead Free Contract PCB Assembly , 2oz Surface Mount PCB Assembly
Low Dk HASL Lead Free Surface mount Contract PCB Assembly
Contract PCB Assembly Introduction
The standard wording of PCBA is PCB Assembly . PCBA can be understood as a finished circuit board. The essence is PCB and component assembly. PCB is a printed circuit board and a support for electronic components. PCB procurement and patch processing are two different production methods.
Factory Capacity
| Layers | 1 - 46 Layers |
| Substrate | FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI |
| Max. panel size | 700x610mm , Customized |
| Board thickness | 0.3 mm - 3.5 mm |
| Copper thickness | 1/3 oz. to 6 oz. (outer) (Max) |
| Hole | > 0.15mm. |
| Aspect Ratio | 10 : 1 |
| Min. track width | 3.0 mils(partial) |
| Min. track space | 3.0mils(partial) |
| Min. S/M bridge | 3mil |
| Hole plugging diameter | 0.3 mm~0.55 mm. |
| Impedance tolerance | +/- 10%. |
| Color of S/M | green,white,black,red,orange,yellow,blue,purple |
| Surface treatment | OSP,HAL,HAL LF, ENIG,Hard gold,Imm Ag,Imm Sn,Peelable soldermask,Carbon ink print,Selective hard gold |
Our service
PCB Design & Layout
PCB Prototyping
PCB Fabrication
Turn Prototype PCB Assembly
PCB Assembly Services
PCB'A
Workshop & Equipment
AL-SPI-IA
solder paste printing equipment
wave-soldering
automatic printing equipment
60times magnifying glass
material baking equipment
X-ray welding inspection
Semi-automatic printing equipment
component counting equipment
Online AOI detector
Reflow welding equipment
Mydata welding equipment
Contract PCB Assembly Application
Aprospace , Auto Industry ,Communication, Indutrial Control , Medical device , Smart Home. Automotive ,etc.
Delivery Time
| Product Type | Qty | Normal lead time | Quick-turn lead time |
| SMT+DIP | 1-50 | 1WD-2WD | 8H |
| SMT+DIP | 51-200 | 2WD-3WD | 1.5WD |
| SMT+DIP | 201-2000 | 3WD-4WD | 2WD |
| SMT+DIP | ≥2001 | 4WD-5WD | 3WD |
| PCBA(2-4Layer) | 1-50 | 2.5WD-3.5WD | 1WD |
| PCBA(2-4Layer) | 51-2000 | 5WD-6WD | 2.5WD |
| PCBA(2-4Layer) | ≥2001 | ≥7WD | 5WD |
| PCBA(6-10Layer) | 1-50 | 3WD-4WD | 2.5WD |
| PCBA(6-10Layer) | 51-2000 | 7WD-8WD | 6WD |
| PCBA(10-HDILayer) | 1-50 | 7WD-9WD | 5WD |
| PCBA(10-HDILayer) | 51-2000 | 9WD-11WD | 7WD |
