HDI PCB Introduction


HDI PCB, also known as high-density interconnect PCB, is a kind of PCB with a higher wiring density per unit area than traditional boards. HDI boards are more compact and have smaller vias, pads, copper traces and spaces. As a result, HDIs have denser wiring resulting in lighter weight, more compact, lower layer count PCBs. HDI PCB is more fit into the little spaces and have a smaller amount of mass than conservative PCB designs.


Factory Capabilities


Item Capabilities
Number of Layers 1 - 36layers
Order Quantity 1pc - 10000+pcs
Material FR4 standard Tg 140°C,FR4 High Tg 170°C, FR4 and Rogers combined lamination
Board Size 700*610mm
Board Thickness 0.3mm - 3.5mm
Copper Weight (Finished) 0.33oz - 6.0oz
Min Tracing/Spacing 3mil
Solder Mask Sides As per the file
Solder Mask Color Green, White, Blue, Black, Red, Yellow
Silkscreen Sides As per the file
Silkscreen Color White, Black, Yellow ,Etc
Surface Finish HASL - Hot Air Solder Leveling
Lead Free HASL - RoHS
ENIG - Electroless Nickle/Immersion Gold - RoHS
Immersion Silver - RoHS
Immersion Tin - RoHS
OSP - Organic Solderability Preservatives - RoHS
Min Annular Ring 4mil, 3mil - laser drill
Min Drilling Hole Diameter 6mil, 4mil - laser drill
HDI Capabilities HDI ELIC (5+2+5)
Other Techniques Flex-rigid combination
Via In Pad
Buried Capacitor (only for Prototype PCB total area ≤1m²)



The types of HDI PCB

1.through vias from surface to surface,
2.with buried vias and through vias,
3.two or more HDI layer with through vias,
4.passive substrate with no electrical connection,
5.coreless construction using layer pairs
6.alternate constructions of coreless constructions using layer pairs.



Blind Buried Vias Hole High Density PCB HDI PCB Stackup 0


Work flow for HDI


Board Cut - Inner Wet film -DES - AOI - Brown Oxido - Outer Layer Press - Out Layer Lamination - X-RAY & Rounting - Copper reduce & brown oxide - Laser Drilling - Drilling - Desmear PTH - Panel plating - Outer Layer dry film - Etching - AOI- Impedance Testing - S/M Pluged hole - Solder Mask - Component Mark - Impedance testing - Immersion Gold -V-cut - Routing - Electrical Test - FQC - FQA -Package -Shipment


Blind Buried Vias Hole High Density PCB HDI PCB Stackup 1


Our Service


PCB design:
we can provide circuit design & PCB layout support.

SMT Assembly:
Leading edge surface mount population technologies.

PTH Assembly:
RoHS compliant wave soldering & hand soldering capabilities.

PCB Fabrication:
You only need provide Gerber files or other design files .

Component procurement:
we have rich experience purchasing & material control expertise team.

Product Assembly:
Complete turnkey solutions

Function Test & Inspection:
We offer test & inspection services on PCB & Assembly
(X-ray,ICT, AOI and Functional tests)



Blind Buried Vias Hole High Density PCB HDI PCB Stackup 2




Blind Buried Vias Hole High Density PCB HDI PCB Stackup 3


Advantages of HDI PCB


1.High Component Density
3.Lightweight Boards
4.Fast Processing
5.Save Number of Layers
6.Accommodate Low Pitch Packages
7.High Reliability



HDI PCB Application Field


Automotive and aerospace industries, where lower weight can mean more efficient operation, have been utilizing HDI PCBs at an increasing rate. such as onboard WiFi and GPS, rearview cameras and backup sensors rely on HDI PCBs. As automotive technology continues to advance, HDI tech will likely play an increasingly important role.


HDI PCBs are also prominently featured in medical devices; advanced electronic medical devices such as equipment for monitoring, imaging, surgical procedures, laboratory analysis etc., and incorporate HDI boards. The high-density technology promotes improved performance and smaller, more cost-effective devices, potentially improving the accuracy of monitoring and medical testing.


Industrial automation requires abundant computerization, and IoT devices are becoming more common in manufacturing, warehousing, and other industrial settings. Many of these advanced equipment employ HDI technology. Today, businesses use electronic tools to keep track of inventory and monitor equipment performance. Increasingly, machinery includes smart sensors that collect usage data and connect to the internet to communicate with other smart devices, as well as to relay information to management and help optimize operations.


Except mentioned above, you'll also can find high-density interconnect PCBs in all types of digital devices, like smartphones and tablets, in automobiles, aircraft , mobile /cellular phones, touch-screen devices, laptop computers, digital cameras, 4/5G network communications, and military applications such as avionics and smart munitions.



Delivery Time


Product Type Qty Normal lead time Quick-turn lead time
SMT+DIP 1-50 1WD-2WD 8H
SMT+DIP 51-200 2WD-3WD 1.5WD
SMT+DIP 201-2000 3WD-4WD 2WD
SMT+DIP ≥2001 4WD-5WD 3WD
PCBA(2-4Layer) 1-50 2.5WD-3.5WD 1WD
PCBA(2-4Layer) 51-2000 5WD-6WD 2.5WD
PCBA(2-4Layer) ≥2001 ≥7WD 5WD
PCBA(6-10Layer) 1-50 3WD-4WD 2.5WD
PCBA(6-10Layer) 51-2000 7WD-8WD 6WD
PCBA(10-HDILayer) 1-50 7WD-9WD 5WD
PCBA(10-HDILayer) 51-2000 9WD-11WD 7WD




Blind Buried Vias Hole High Density PCB HDI PCB Stackup 4


Common packaging

PCB: Vacuum packaging with carton box
PCBA: ESD packaging with carton box


Blind Buried Vias Hole High Density PCB HDI PCB Stackup 5





Blind Buried Vias Hole High Density PCB HDI PCB Stackup 6






Q1:What kind of PCB file format can you accept for production?


Q2:Is my PCB files safe when I submit them to you for manufacturing?

We respect customer's copyright and will never manufacture PCB for someone else with your files unless we receive written permission from you, nor we'll share these files with any other 3rd parties.


Q3:What payments do you accept ?
-Telex Transfer(T/T),Western Union,Letter of Credit(L/C)
-Paypal,AliPay,Credit Card


Q4:How to get the PCB?
A:For small packages, we will ship the boards to you by DHL,UPS,FedEx,EMS. Door to door service! You will get your PCBs at your home.
B:For heavy goods more than 300kg, we may ship your boards by ship or by air to save freight cost. Of course, if you have your own forwarder, we may contact them for dealing with your shipment.


Q5:What is your minimum order quantity?
Our MOQ is 1 PCS.


Q6: Can we visit your company?

No problem. You are welcome to visit us in Beijing. Or the branch factory is in Tianjin.


Q7: How can you ensure the quality of the PCB?
Our PCBs are 100% test including Flying Probe Test, E-test and AOI.
