1/3OZ Pcba Assembly Prototype HASL Pb Free Soldering Immersion Tin DIP THT

1/3OZ Pcba Assembly Prototype HASL Pb Free Soldering Immersion Tin DIP THT

  • High Light

    1/3oz pcba assembly prototype

    ,

    dip pcba assembly prototype

    ,

    1/3oz prototype electronics assembly

  • Product Name
    Lead-Free PCB Assembly
  • Base Material
    FR-4, HASL, Aluminum, FR1, High TG, Ceramic Etc
  • Copper Thickness
    1/3OZ, 1OZ, 2OZ...... 6OZ
  • Min. Line Width/spacing
    0.030mm/0.030mm
  • Board Thickness
    Core Thickness 0.05mm-1.5mm ,Fineshed Board Thickness 0.3-3.5mm
  • Min. Hole Size
    Laser 0.05mm ; Mechnical 0.15
  • Service
    One-stop Service,PCB & PCBA,ODM And OEM
  • Legond Color
    White
  • Layer
    1~48 Layers
  • Pcb Standard
    IPC-II Standard,IPC-A-610 D,Customized
  • Place of Origin
    CHINA
  • Brand Name
    HNL-PCBA
  • Certification
    ISO9001,IS16949, ISO14001,ROHS ,UL, IPC-A ,QC080000
  • Model Number
    PCB Assembly 04
  • Minimum Order Quantity
    1 PC
  • Price
    Negotiable
  • Packaging Details
    ESD packaging with carton box
  • Delivery Time
    1-7days
  • Payment Terms
    T/T, Western Union, L/C, MoneyGram
  • Supply Ability
    10,000,000 Point /Day

1/3OZ Pcba Assembly Prototype HASL Pb Free Soldering Immersion Tin DIP THT

HASL Pb-free Soldering Immersion Tin DIP THT Lead Free PCB Assembly



Lead Free PCB Assembly Introduction



More then 15 years of custom PCB and PCBA manufacturer, PCB electronic board assembly programmable Pcba. Lead free manufacturing primarily comes in lead-free solder technology, lead-free components and materials. Lead is the most comprehensive substance because it plays a fundamental & key role in electronic plating. Therefore, It is the optimal prescription with lead-free solutions for RoHS-compatible PCB assembly.



PCBA CAPABILITIES



FACTORY CAPABILITIES
No. Items 2020
1 HDI Capabilities HDI ELIC(5+2+5)
2 Max layer count 46L
3 Board Thickness Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm
4 Min.Hole Size Laser 0.05mm
Mechnical 0.15
5 Min Line Width/Space 0.030mm/0.030mm
6 Copper Thickness 1/3oz-6oz
7 Size Max Panel size 700x610mm
8 Registration Accuracy +/-0.05mm
9 Routing Accuracy +/-0.05mm
10 Min.BGA PAD 0.125mm
11 Max Aspect Ratio 10:01
12 Bow and Twist 0.50%
13 Impedance Control Tolerance +/-5%
14 Daily output 4,000m2 (Max capacity of equipment)
15 Surface Finishing HASL Lead Free /ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD
16 Raw Material FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI

PCB assembly process



Drilling---Exposure---Plating---Etaching & Stripping---Punching---Electrical Testing---SMT--Wave Soldering---Assembling---ICT--Function Testing---Temperature & Humidity Testing
