|Product Name:||PCB SMT Assembly||Material:||FR-4, Aluminum, FR1, High TG, Ceramic Etc|
|Copper Thickness:||1/3OZ, 0.5OZ, 1OZ, 2OZ, 3OZ, 4OZ,5OZ 6OZ||Min. Line Width:||0.030mm|
|Board Thickness:||Core Thickness 0.05mm-1.5mm ,Fineshed Board Thickness 0.3-3.5mm||Min. Hole Size:||Laser 0.05mm ; Mechnical 0.15|
|Surface Finishing:||HASL, ENIG, OSP, Lead Free HASL, HASL/OSP/ENIG||Service:||One-stop Service,PCB & PCBA,ODM And OEM|
|PCB Assembly Method:||Mixed; SMT, DIP, THT||Legond Color:||White|
4OZ Lead Free PCB Assembly,
EMS Lead Free PCB Assembly,
DIP Quick Turn PCB Assembly
PCBA is the abbreviation of Printed Circuit Board Assembly in English, that is to say, PCB blank board goes through SMT loading, or the entire process of DIP plug-in, referred to as PCBA, and the standard way of writing in Europe and America is PCB'A.
Haina Lean is an entity enterprise that specializes in electronic product design and development, supply chain management, PCBA and one-stop (OEM) production services for complete machine products.
Also it owns profuse experience in manufacturing PCB,owned experienced technical R & D technology team, young and professional sales and customer service team, experienced and professional procurement team and assembly testing team, which make sure the products quality of the pass rate, on-time delivery rate of customer orders. Welcome to visit our factory!
|1||HDI Capabilities||HDI ELIC (4+2+4)||HDI ELIC(5+2+5)|
|2||Max layer count||32L||36L|
|3||Board Thickness||Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm||Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm|
|4||Min.Hole Size||Laser 0.075mm||Laser 0.05mm|
|Mechnical 0.15||Mechnical 0.15|
|5||Min Line Width/Space||0.035mm/0.035||0.030mm/0.030mm|
|7||Size Max Panel size||700x610mm||700x610mm|
|11||Max Aspect Ratio||10:01||10:01|
|12||Bow and Twist||0.50%||0.50%|
|13||Impedance Control Tolerance||+/-8%||+/-5%|
|14||Daily output||3,000m2 (Max capacity of equipment)||4,000m2 (Max capacity of equipment)|
|15||Surface Finishing||HASL Lead Free /ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD|
|16||Raw Material||FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI|
|Material||FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC|
|Surface finish||HASL,OSP,Immersion gold,Flash Gold Finger|
PCB assembly process
Drilling---Exposure---Plating---Etaching & Stripping---Punching---Electrical Testing---SMT--Wave Soldering---Assembling---ICT--Function Testing---Temperature & Humidity Testing
Independent quotation system to quickly serve the market
High-tech PCB and PCB assembly production line
A team of experienced electronic component procurement engineers
4.SMT post soldering
Dust-free workshop, high-end SMT patch processing
|Product Type||Qty||Normal lead time||Quick-turn lead time|
Printed circuit boards And PCB Assembly are mainly used for many communication industry ,Aprospace ,Auto Industry ,Communication,Indutrial Control ,Medical device ,Smart Home,consumer electronics ,automotive electronics , audio and video, optoelectronics, robotics, hydroelectric power, aerospace, education, power supply, printer ,Auto Industry ,Smart Home.etc.
1.PCB: Vacuum packaging with carton box
2.PCBA: ESD packaging with carton box
Q1:What service do you have?
A1: We provide turnkey solution including RD, PCB fabrication, SMT, final assembly,testing and other
Q2:What are the main products of your PCB/PCBA services?
A2:Our PCB/PCBA services are mainly for the industries including Medical, Automotive, Energy,
Metering/Measurements. Consumer Electronics.
Q3:How can we ensure our information should not let third party to see our design?
A3: We are wiling to sign NDA effect by customer side locallaw and promising to keep customers datain highconfidential level.
Q4:What does Parason need for a customized PCB order?
A4:When you place a PCB order, the customers need to provide Gerber or pcb file.If you do not have the fileinthe correct format, you can send all the details related to the products.
Q5:What will be needed for a customized PCBA order?
A5: When you place a PCBA order, you need to provide Gerber or pcb file and the BOM list to us.
Q6:Do you have an minimum order quantity?
A6:We accept order with as low as a quantity of 1 (piece or panel)
Haina lean Electronics Co., Ltd is a one-stop EMS supplier integrating PCB design, PCB manufacturing, Component sourcing and PCB assembly.
The company is specialized in electronic products supporting processing services, mainly to undertake circuit board design, layout production, components procurement, PCB plate making, circuit board welding assembly debugging and other OEM/ODM services.
Here is strong component supply chain and procceurement team. Prototype and mass production are available. Competitive price is for high-quality and services. Exported to worldwide customer in US, Europe, Canada.
Contact Person: Silvia
