    THT PCB Assembly
  • Material
    FR4, Halogen Free, Aluminum, CEM-1, High TG
  • Copper Thickness
    1OZ ,2OZ ... 6OZ
  • Min. Line/spacing
  • Board Thickness
    1.6mm, Up To 3.5mm As Request
  • Hole Size
    0.3mm (Min. Hole Laser 0.05mm; Mechnical 0.15)
  • Surface Finishing
  • Testing Service
    Function Test,E-test Or Fly-probe According To Order Quantity,Solder Paste Testing
  • Color
    Blue,green, On Your Request
  • Application
    Video Security, Monitoring System Etc.
  • Place of Origin
  • Brand Name
  • Certification
    ISO9001,IS16949, ISO14001,ROHS ,UL, IPC-A ,QC080000
  • Model Number
    PCB Assembly 06
  • Minimum Order Quantity
    1 PC
  • Price
  • Packaging Details
    ESD packaging with carton box
  • Delivery Time
  • Payment Terms
    T/T, Western Union, L/C, MoneyGram
  • Supply Ability
    10,000,000 Point /Day

Oem 1oz Multilayer Smt Through Hole Pcb Assembly Soldering

EMS 1oz Multilayer SMT PCB'A Through Hole Soldering Pcb Assembly


Through Hole PCB Assembly Introduction


Through-hole PCB assembly means to insert the electronic components into existing through holes on a printed circuit board (PCB) by the pins of the component by an automatic insert mount machine or manual soldering. These terminals are then soldered manually or through reflow soldering to hold the components in place and connect it to the conductive path.

Our assemblers team is of highly trained, qualified and experienced, who work under the supervision of qualified engineering staff.


Supplier Type: OEM/ODM
Place of Origin: Beijing , China
Certificate: ISO9001 : 2016
PCB type: Rigid, flexible, rigid-flexible
Service: PCB Design /PCB layout /PCBA(SMT/DIP)/Component Procurement
Test service: AOI/X-RAY/Function test
Copper Thickness: 0.3 OZ-6OZ
Base Material: FR-4; High TG FR-4; Aluminum; CEM-1; CEM-3;
Board Thickness: 0.2mm-4mm
Surface Finishing: HASL lead free, LF HASL, Imm Gold, Imm Silver, OSP etc

PCB Assembly types: Surface mount; Thro-hole; Mixed technology (SMT & Thru-hole); Single or double sided placement; Conformal coating etc.




Base material FR4,High-TG FR4,CEM3,aluminum, High frequency(Rogers,Taconic,Aron,PTFE,)
Layers 1-46
Copper Thickness 0.3oz,0.5oz, 1oz, 2oz, 3oz,4oz,5oz, 6oz
Dielectric Thickness 0.05mm, 0.075mm, 0.1mm,0.15mm,0.2mm
board Core Thickness 0.4mm,0.6mm, 0.8mm, 1.0mm, 1.2mm,
1.5mm, 2.0mm, 3.0mm and 3.2mm
Board Thickness 0.3mm - 4.0mm
Thickness Tolerance +/-10%
Surface Finishing HASL lead free,ENIG,Plated Gold,Immersion Gold,OSP
Solder Mask Color Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue
Legend Color Black, White etc
Parts Procurement Full Turnkey, Partial Turnkey, Kitted / Consigned
Component types SMT 01005 or larger
BGA 0.4mm pitch, POP (Package on Package)
WLCSP 0.35mm pitch
Hard metric connectors
Cable & wire
PCBA Capability
Material Type Item Min Max
PCB Dimension (length,width, 50*40*0.38 600*400*4.2
Components Chip&IC 1005 55mm
BGA Pitch 0.3mm -
QFP Pitch 0.3mm -

Other Techniques: Free DFM Review
                              Box Build Assembly
                              100% AOI test and X-ray test for BGA
                              Components cost-down
                              Function test as custom
                              Protection technology


Automotive PCBA process
