Bga Components Integrated Fr4 Pcb Assembly 1oz

BGA Components Integrated PCB Assembly Use FR4 Printed Circuit Board


FR4 Printed Circuit Board Introduction


PCB is the foundation. All of the other electronic components are mounted on the PCB(printed circuit boards)as partner's requires. PCB Surface Finishing could be HASL Lead Free /ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD. PCB Raw Material could be FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI.

Our strengths include:

Surface Mount Technology (SMT) Assembly;

BGA & Mixed Technology Assembly;

Through-Hole Technology Assembly;

Automatic PCB Optical Inspection(AOI);

Final Product Assembly (Box Build) & Custom Packaging;

Prototype & Rapid Turn-Around PCB Assembly;

RoHS & Lead-Free Compliance




No. Items 2020
1 HDI Capabilities HDI ELIC(5+2+5)
2 Max layer count 46L
3 Board Thickness Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm
4 Min.Hole Size Laser 0.05mm
Mechnical 0.15
5 Min Line Width/Space 0.030mm/0.030mm
6 Copper Thickness 1/3oz-6oz
7 Size Max Panel size 700x610mm
8 Registration Accuracy +/-0.05mm
9 Routing Accuracy +/-0.05mm
10 Min.BGA PAD 0.125mm
11 Max Aspect Ratio 10:01
12 Bow and Twist 0.50%
13 Impedance Control Tolerance +/-5%
14 Daily output 4,000m2 (Max capacity of equipment)
16 Raw Material FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI



PCB Assembly Process


Bga Components Integrated Fr4 Pcb Assembly 1oz 0


Other PCB Assembly & PCB products as following:


Bga Components Integrated Fr4 Pcb Assembly 1oz 1

Bga Components Integrated Fr4 Pcb Assembly 1oz 2


Delivery Time


Product Type Qty Normal lead time Quick-turn lead time
SMT+DIP 1-50 1WD-2WD 8H
SMT+DIP 51-200 2WD-3WD 1.5WD
SMT+DIP 201-2000 3WD-4WD 2WD
SMT+DIP ≥2001 4WD-5WD 3WD
PCBA(2-4Layer) 1-50 2.5WD-3.5WD 1WD
PCBA(2-4Layer) 51-2000 5WD-6WD 2.5WD
PCBA(2-4Layer) ≥2001 ≥7WD 5WD
PCBA(6-10Layer) 1-50 3WD-4WD 2.5WD
PCBA(6-10Layer) 51-2000 7WD-8WD 6WD
PCBA(10-HDILayer) 1-50 7WD-9WD 5WD
PCBA(10-HDILayer) 51-2000 9WD-11WD 7WD


FR4 Printed Circuit Board Application Field


Our products are widely used in communication equipment, industrial control, consumer electronics, medical equipment, aerospace, light-emitting diode lighting, automotive electronics etc.


Bga Components Integrated Fr4 Pcb Assembly 1oz 3




Bga Components Integrated Fr4 Pcb Assembly 1oz 4

Bga Components Integrated Fr4 Pcb Assembly 1oz 5


Common packaging


1.PCB: Vacuum packaging with carton box
2.PCBA: ESD packaging with carton box


Bga Components Integrated Fr4 Pcb Assembly 1oz 6

Bga Components Integrated Fr4 Pcb Assembly 1oz 7





What's your MOQ ?
No Moq ,We accept small orders as well as mass production.


For small quantity orders, can you produce prototype PCB?

Haina lean Electronics Co., has the capability to produce circuit boards in any amount.

Can You provide fast rotating PCB ?
Yes , we can provide fast service 24 hours .

What are the services you can provide ?
One-stop contract manufacturing
PCB board, PCB Design & Layout, PCB Assembly, PCBA programming & functional testing, Electronic components purchasing service, Enclosure molding & final assembly with labels,instructions,enclosure, boxes.


Whether all PCBA s will be tested before delivery ?
Yes , we will test each piece of PCBA product under your testing methods ,to ensure quality and functionality .

Do you provide OEM service ?
Yes ,we offer PCB and PCBA OEM Service , we manufacture the PCB and PCBA products to your design and requirements .


Shipping Cost ?
The shipping cost is determined by the destination ,weight ,packing size of the goods .We can provide shipping, air, land, express and other transportation services .
