We know that the development of medical PCB applications is as fast as the medical device industry itself.
Haina Lean provides you with the best PCB assembly service solutions.
We are technical experts in SMT assembly, DIP assembly, turnkey PCB assembly and main PCB assembly services. In addition to being an extensive and sophisticated PCB assembly manufacturer, we also care about our customers and provide a series of PCB assembly services to meet their needs.
|1||HDI Capabilities||HDI ELIC (4+2+4)||HDI ELIC(5+2+5)|
|2||Max layer count||32L||36L|
|3||Board Thickness||Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm||Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm|
|5||Min Line Width/Space||0.035mm/0.035||0.030mm/0.030mm|
|7||Size Max Panel size||700x610mm||700x610mm|
|11||Max Aspect Ratio||10:1||10:1|
|12||Bow and Twist||0.50%||0.50%|
|13||Impedance Control Tolerance||+/-8%||+/-5%|
|14||Daily output||3,000m2 (Max capacity of equipment)||4,000m2 (Max capacity of equipment)|
|15||Surface Finishing||HASL Lead Free /ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD|
|16||Raw Material||FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI|
|Material||FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC|
|Surface finish||HASL,OSP,Immersion gold,Flash Gold Finger|
Medical PCB Assembly Technologies
1. Multi-layer / High Density Interconnect (HDI) PCBs ; 2. THT (Through-Hole Technology );3. Flex & Rigid-Flex ;
4. SMT & mini SMT ; 5. BGA techonology ; 6. Reflow Soldering ;7. Wave-soldering ;8. Conformal Coating ;etc.
1.PCB Design & Layout 2.PCB Prototyping 3.PCB Fabrication 4.Turn Prototype PCB Assembly
5.PCB Assembly Service 6.Contract PCB Assembly 7.Trunkey PCB Assembly 8.Components sourcing,
9.Function test 10.conformal coating 11.complete assembly
Our assembly process has been designed to meet all variations of PCBs, including single- or double-sided boards, Multilayer , rigid ,flexible circuits and Mixed technology. We run both leaded and RoHS/Lead-Free Surface Mount Technology (SMT) lines as well as wave solder equipment for both RoHS and leaded processes. Our manufacturing process allows for the highest quality product through process automation, environmental controls, automatic optical inspection (AOI) and flying probe at the best competitive price.
Printed circuit boards And PCB Assembly are mainly used for many communication industry, medical equipments, consumer electronics ,automotive electronics , audio and video, optoelectronics, robotics, hydroelectric power, aerospace, education, power supply, printer ,Auto Industry ,Smart Home.etc.
|Product Type||Qty||Normal lead time||Quick-turn lead time|
Beijing Haina lean Electronics Co.,Ltd is one of the most professional PCB manufacture in Beijing,China. With more then 10 years of development, Haina Lean Electronics turns into a first class manufacture of HDI PCB ,with production capability 4000 square meters.
Our factory is providing high quality bare PCB, PCB layout design service and PCB assembly service,including components sourcing, function test,conformal coating and complete assembly for clients all.
From 2000 onwards, Zhang has worked in Hong Kong Yilianda Circuit Board Group (Hong Kong enterprises), meiko Group China Factory (Japanese enterprises), Shenzhen Mingyang Circuit Technology Co., Ltd (Hong Kong capital) and other well-known enterprises, with rich production management experience. After joining our team in 2018, we have greatly improved the production detail control, quality abnormal control, complex product process improvement, staff habit formation, staff quality improvement and so on.
