We are a manufacturer specializing in high-density surface mount assembly, from prototype production to mass production PCB assembly.
Our Services :
Using Gerber files for pick and place data
First article electronic comparison inspection
Vision Engineering Lynx microscope with compound viewing
Full or partial component procurement
Mechanical assembly - Box build
Conventional through-hole assembly facilities
|1||HDI Capabilities||HDI ELIC (4+2+4)||HDI ELIC(5+2+5)|
|2||Max layer count||32L||36L|
|3||Board Thickness||Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm||Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm|
|5||Min Line Width/Space||0.035mm/0.035||0.030mm/0.030mm|
|7||Size Max Panel size||700x610mm||700x610mm|
|11||Max Aspect Ratio||10:1||10:1|
|12||Bow and Twist||0.50%||0.50%|
|13||Impedance Control Tolerance||+/-8%||+/-5%|
|14||Daily output||3,000m2 (Max capacity of equipment)||4,000m2 (Max capacity of equipment)|
|15||Surface Finishing||HASL Lead Free /ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD|
|16||Raw Material||FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI|
|Material||FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC|
|Surface finish||HASL,OSP,Immersion gold,Flash Gold Finger|
Medical PCB Assembly Technologies
1. Multi-layer / High Density Interconnect (HDI) PCBs ; 2. THT (Through-Hole Technology );3. Flex & Rigid-Flex ;
4. SMT & mini SMT ; 5. BGA techonology ; 6. Reflow Soldering ;7. Wave-soldering ;8. Conformal Coating ;etc.
1.PCB Design & Layout 2.PCB Prototyping 3.PCB Fabrication 4.Turn Prototype PCB Assembly
5.PCB Assembly Service 6.Contract PCB Assembly 7.Trunkey PCB Assembly 8.Components sourcing,
9.Function test 10.conformal coating 11.complete assembly
Our assembly process has been designed to meet all variations of PCBs, including single- or double-sided boards, Multilayer , rigid ,flexible circuits and Mixed technology. We run both leaded and RoHS/Lead-Free Surface Mount Technology (SMT) lines as well as wave solder equipment for both RoHS and leaded processes. Our manufacturing process allows for the highest quality product through process automation, environmental controls, automatic optical inspection (AOI) and flying probe at the best competitive price.
Printed circuit boards And PCB Assembly are mainly used for many communication industry, medical equipments, consumer electronics ,automotive electronics , audio and video, optoelectronics, robotics, hydroelectric power, aerospace, education, power supply, printer ,Auto Industry ,Smart Home.etc.
Beijing Haina lean Electronics Co.,Ltd is one of the most professional PCB manufacture in Beijing,China. With more then 10 years of development, Haina Lean Electronics turns into a first class manufacture of HDI PCB ,with production capability 4000 square meters.
Our factory is providing high quality bare PCB, PCB layout design service and PCB assembly service,including components sourcing, function test,conformal coating and complete assembly for clients all.
We have profuse experience in manufacturing PCB,owned experienced technical R & D technology team, young and professional sales and customer service team, experienced and professional procurement team and assembly testing team, which make sure the products quality of the pass rate, on-time delivery rate of customer orders.
Our services include: circuit board design and layout, 2-46 layers PCB manufacturing, professional FPC production, electronic components purchasing, SMT professional processing, Soldering and Assembly, especially sample and small bulk orders. we have the advantages of a quick quote, fast production, fast delivery.
