Lead Free Rohs 3oz Medical Pcba Customized Turn Key

Lead Free Rohs 3oz Medical Pcba Customized Turn Key

  • High Light

    lead free medical pcba


    3oz medical pcba


    3oz medical pcb assembly

  • Product Name
    Medical PCB Assembly
  • Material
    Fr4 High Tg
  • Copper Thickness
  • Min. Line Width/spacing
  • Board Thickness
    0.3mm-3.5mm; As Requires
  • Surface Finishing
    HASL, OSP, ENIG, HASL Lead Free, Immersion Gold Etc.
  • PCB Assembly Method
    Mixed; SMT, DIP, THT,BGA
  • Pcb Test
    Flying Probe And AOI (Default)/Fixture Test,Flying-Probe PCB Test
  • Type
    Electronic Board,printing Circuit Board,Customizable,PCBA Design
  • Solder Mask
    Orange,green/black/white/red/blue Etc.
  • Place of Origin
  • Brand Name
  • Certification
    ISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000
  • Model Number
    PCB Assembly 04
  • Minimum Order Quantity
    1 PC
  • Price
  • Packaging Details
    ESD packaging with carton box
  • Delivery Time
  • Payment Terms
    T/T, Western Union, L/C, MoneyGram
  • Supply Ability
    10,000,000 Point /Day

Lead Free Rohs 3oz Medical Pcba Customized Turn Key

Lead Free Rohs 3oz Customized Turn Key Pcba Medical PCB Assembly


Medical PCB Assembly Introduction


We know that the development of medical PCB applications is as fast as the medical device industry itself.

Haina Lean Electronic CO., LTD offers the most advanced manufacturing services of electronic assembly for medical devices.

Medical devices which include printed circuit board assemblies have special safety considerations because they are electrically powered.

Haina Lean CO., LTD offers complete solutions for Printed Circuit Board Assembly as follows:

BGA & Mixed Technology Assembly
Surface Mount Technology (SMT Assembly)
Through-Hole Technology Assembly
0402 Small Size Component Assembly
RoHS & Lead-Free Compliance
Automatic PCB Optical Inspection
Final Product Assembly (Box Build) & Custom Packaging
PCB Testing, and Troubleshooting
Prototype & Rapid Turn-Around PCB Assembly



Base material FR4,High-TG FR4,CEM3,aluminum, High frequency(Rogers,Taconic,Aron,PTFE,)
Layers 1-46
Copper Thickness 0.3oz,0.5oz, 1oz, 2oz, 3oz,4oz,5oz, 6oz
Dielectric Thickness 0.05mm, 0.075mm, 0.1mm,0.15mm,0.2mm
board Core Thickness 0.4mm,0.6mm, 0.8mm, 1.0mm, 1.2mm,
1.5mm, 2.0mm, 3.0mm and 3.2mm
Board Thickness 0.3mm - 4.0mm
Thickness Tolerance +/-10%
Surface Finishing HASL lead free,ENIG,Plated Gold,Immersion Gold,OSP
Solder Mask Color Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue
Legend Color Black, White etc
Assembly Types Surface mount
Mixed technology (SMT & Thru-hole)
Single or double sided placement
Conformal coating
Shield cover assembly for EMI emission control
Parts Procurement Full Turnkey, Partial Turnkey, Kitted / Consigned
Component types SMT 01005 or larger
BGA 0.4mm pitch, POP (Package on Package)
WLCSP 0.35mm pitch
Hard metric connectors
Cable & wire
Other Techniques Free DFM Review
Box Build Assembly
100% AOI test and X-ray test for BGA
Components cost-down
Function test as custom
Protection technology


Our SMT capabilities:


SMT Assembly: SMT provides a flexible high technology. These solutions include:

7 high-speed placement machines,

7 automatic printers with fiducial alignment,

2 X-ray machines,

BGA maintenance machines,

ICT test machines


Our DIP function:


A-8 semi-assembly production line with four wave soldering machines

1 U-shaped automatic assembly line for box-type building products with test stations

High temperature / low temperature aging test furnace B-4 for products required for aging test

With time control and temperature control

All products are 100% inspected and tested during the DIP process

Haina lean Electronics Co.,Ltd is a competitive China customize pcba for medical breathing machine OEM manufacturer, supplier and vendor, you can get quick turn customize pcba for medical breathing machine production prototypes and samples from our factory.

Hot Tags: customize pcba for medical breathing machine, China, supplier, manufacturer, factory, OEM manufacturer, vendor, samples, production, prototypes, quick turn


Medical PCB Assembly Introduction​ Process


1.Solder Paste stenciling---2.Surface Mount Technology (Pick and Place)---3.Reflow Soldering---4.Inspection and Quality Control---5.Through-Hole Component Insertion (DIP Process)---6.Final Inspection and Functional Test

Lead Free Rohs 3oz Medical Pcba Customized Turn Key 0

Lead Free Rohs 3oz Medical Pcba Customized Turn Key 1

Lead Free Rohs 3oz Medical Pcba Customized Turn Key 2


Medical PCB Assembly Introduction Delivery Time


Product Type Qty Normal lead time Quick-turn lead time
SMT+DIP 1-50 1WD-2WD 8H
SMT+DIP 51-200 2WD-3WD 1.5WD
SMT+DIP 201-2000 3WD-4WD 2WD
SMT+DIP ≥2001 4WD-5WD 3WD
PCBA(2-4Layer) 1-50 2.5WD-3.5WD 1WD
PCBA(2-4Layer) 51-2000 5WD-6WD 2.5WD
PCBA(2-4Layer) ≥2001 ≥7WD 5WD
PCBA(6-10Layer) 1-50 3WD-4WD 2.5WD
PCBA(6-10Layer) 51-2000 7WD-8WD 6WD
PCBA(10-HDILayer) 1-50 7WD-9WD 5WD
PCBA(10-HDILayer) 51-2000 9WD-11WD 7WD


Electronic Board Assembly Application Field


Our products are widely used in

1.communication equipment,

2.industrial control,

3.consumer electronics,

4.medical equipment,


6.light-emitting diode lighting,

7.automotive electronics etc.


Lead Free Rohs 3oz Medical Pcba Customized Turn Key 3




Lead Free Rohs 3oz Medical Pcba Customized Turn Key 4

Lead Free Rohs 3oz Medical Pcba Customized Turn Key 5


Common packaging


1.PCB: Vacuum packaging with carton box
2.PCBA: ESD packaging with carton box


Lead Free Rohs 3oz Medical Pcba Customized Turn Key 6


We offer competitive pricing, as well as flexible shipment plans to you. Our engineers is qualified and experienced in producing surface-mount (SMT), through-hole (THT) and mixed-technology components and fine-pitch parts and ball grid arrays (BGAs) for high-density FR-4 PCBs.

From 2000 onwards, Zhang has worked in Hong Kong Yilianda Circuit Board Group (Hong Kong enterprises), meiko Group China Factory (Japanese enterprises), Shenzhen Mingyang Circuit Technology Co., Ltd (Hong Kong capital) and other well-known enterprises, with rich production management experience. After joining our team in 2018, we have greatly improved the production detail control, quality abnormal control, complex product process improvement, staff habit formation, staff quality improvement and so on.


Our primary products functions in these industries including automotive, industrial control, security, communication, medical and new energy. We’re focusing on providing one-stop EMS(electronic manufacturing services) to clients all over the world.
