Fr4 Enig Iso9001 Double Sided Rapid Pcb Assembly

Fr4 Enig Iso9001 Double Sided Rapid Pcb Assembly

  • High Light

    fr4 rapid pcb assembly


    enig rapid pcb assembly


    double sided rapid pcb assembly

  • Product Name
    Rapid PCBA
  • Material
    FR4, HASL,CEM-1, High TG, Ceramic Etc
  • Copper Thickness
  • Min. Line Width/spacing
  • Board Thickness
  • Min. Hole Size
  • Surface Finishing
  • Legond Color
  • Layers
    As Requires
  • Application
    Electronics Device,LED Products,rigid Fpc, Inductry Controller
  • Place of Origin
  • Brand Name
  • Certification
    ISO9001,IS16949, ISO14001,ROHS ,UL, IPC-A ,QC080000
  • Model Number
    PCB Assembly 06
  • Minimum Order Quantity
    1 PC
  • Price
  • Packaging Details
    ESD packaging with carton box
  • Delivery Time
  • Payment Terms
    T/T, Western Union, L/C, MoneyGram
  • Supply Ability
    10,000,000 Point /Day

Fr4 Enig Iso9001 Double Sided Rapid Pcb Assembly

FR4 ENIG ISO9001 Double Sided Pcb Assembly Contract Rapid PCBA


Rapid PCBA Introduction


BEIJING HAINA LEAN CO., LTD offers custom Rapid PCBA service to go along with our high quality fabrication and components purchasing. PCB blank board goes through SMT loading, or the entire process of DIP plug-in, then referred to as PCBA. And the standard way of writing in Europe and America is PCB'A.

Our factory is a professional PCB & PCB'A manufacturer which has more than 10years history and focus on circuit board design and layout, 2-46 layers PCB manufacturing, professional FPC production, electronic components procurement service, SMT professional processing, Soldering and Assembly, especially sample, small and bulk orders.




Multilayer Circuit Board Assembly Capabilities
Feature Supported Capabilities
Layer Count 1– 48
Materials FR-4/Rogers/Polyimide/Aluminum Clad/High-Temp.
Plating Finish Electrolytic Hard Gold/Soft Gold/ENIG/Nickel/Immersion Silver OSP/Leaded & Lead-Free HAL
Accepted SMD chips 01005, BGA, QFP, QFN, TSOP
Component height 0.2-25mm
Min distance among BGA 0.3mm with X-ray inspection
Assembly Size Min – 50*30mm
Max – 520*570mm
Pick-placement precision ±0.01mm
Board type Rigid PCB, Flexible PCB, Rigid-flex PCB, Copper PCB
Surface Finish HASL, lead free HASL, ENIG, OSP, selective gold, hard gold, bondable gold
Conductor Material Copper, aluminum, carbon, inconel
Insulator Material Polyimide, polyethylene terephthalate
Adhesive Materials Acrylic, epoxy, adhesiveless base
Equipment in our PCBA facilities – Functional, electrical and in-circuit testing equipment
– Optical microscopes
– Multifunction placement machines
Testing ICT, AOI, X-RAY, Functional Test (FCT)


Rapid PCBA fabricating process


Fr4 Enig Iso9001 Double Sided Rapid Pcb Assembly 0

Fr4 Enig Iso9001 Double Sided Rapid Pcb Assembly 1


Rapid PCBA Lead Time


Product Type Qty Normal lead time Quick-turn lead time
SMT+DIP 1-50 1WD-2WD 8H
SMT+DIP 51-200 2WD-3WD 1.5WD
SMT+DIP 201-2000 3WD-4WD 2WD
SMT+DIP ≥2001 4WD-5WD 3WD
PCBA(2-4Layer) 1-50 2.5WD-3.5WD 1WD
PCBA(2-4Layer) 51-2000 5WD-6WD 2.5WD
PCBA(2-4Layer) ≥2001 ≥7WD 5WD
PCBA(6-10Layer) 1-50 3WD-4WD 2.5WD
PCBA(6-10Layer) 51-2000 7WD-8WD 6WD
PCBA(10-HDILayer) 1-50 7WD-9WD 5WD
PCBA(10-HDILayer) 51-2000 9WD-11WD 7WD


Rapid PCBA's Application Field


Printed circuit boards and PCB Assembly are mainly used for many communication industry ,Aprospace ,Auto Industry ,Communication,Indutrial Control ,Medical device ,Smart Home,consumer electronics ,automotive electronics , audio and video, optoelectronics, robotics, hydroelectric power, aerospace, education, power supply, printer ,Auto Industry ,Smart Home.etc.


Fr4 Enig Iso9001 Double Sided Rapid Pcb Assembly 2




Fr4 Enig Iso9001 Double Sided Rapid Pcb Assembly 3

Fr4 Enig Iso9001 Double Sided Rapid Pcb Assembly 4Fr4 Enig Iso9001 Double Sided Rapid Pcb Assembly 5



Common packaging


1.PCB: Vacuum packaging with carton box
2.PCBA: ESD packaging with carton box


Fr4 Enig Iso9001 Double Sided Rapid Pcb Assembly 6



1, What service do you provide?
We provide turnkey solution including PCB fabrication, SMT Process, PCB Assembly,final assembly, Function testing and other value-added service.
2, What is needed for PCB & PCBA quotation?
PCB: Quantity, Gerber file and technic requirements(material,size, surface finish treatment, copper thickness,board thickness).
PCBA: PCB information, BOM,Testing documents.
3, How to keep our product information and design file secret ?
We can sign a NDA effect by customers side local law and promising to keep customers data in high confidential level.
4, What are the main products of your PCB/PCBA services?
Automotive, Medical, Industry Control,IOT,Smart Home,Military.
5, What is your minimum order quantity (MOQ)?
Our MOQ is 1 PCS, sample and mass production all can support.
6.What are the services you can provide ?
One-stop contract manufacturing
PCB Assembly;
PCB Design & Layout
PCBA programming & functional testing;
Electronic components purchasing service;
Enclosure molding & final assembly with labels,instructions,enclosure, boxes.


Company Information


Haina lean Electronics Co., Ltd is a one-stop EMS supplier integrating PCB design, PCB manufacturing, Component sourcing and PCB assembly.

Here is strong component supply chain and procceurement team. Prototype and mass production are available. Competitive price is for high-quality and services. Exported to worldwide customer in US, Europe, Canada.


Fr4 Enig Iso9001 Double Sided Rapid Pcb Assembly 7
