High Light
Low Dk Rapid PCBA
,RoHS Rapid PCBA
,Rapid RoHS PCB Assembly
-
Product NameRapid Pcba
-
LayersMulti-layer ,Double-side
-
Min. Line Spacing0.030mm
-
Board Thickness0.3mm-3.5mm
-
Min. Hole SizeLaser 0.05mm ; Mechnical 0.15
-
Copper Thickness0.3oz 0.6oz 1.0oz 2oz ...... 6oz
-
CertificationISO9001:2015 ,UL ,ROHS
-
ServicePCB/PCBA/Circuit Board/SMT/DIP PCBA Layout And Design
-
Surface TreatmentOSP,HAL,HAL LF,ENIG,Hard Gold,Imm Ag,Imm Sn,Peelable Soldermask,Carbon Ink Print,Selective Hard Gold
-
Base MaterialHigh Tg FR-4, Halogen Free FR-4, Thick Copper FR-4, Aluminium Based, Rogers, Taconic
-
Solder Mask ColorGreen,white,black,red,orange,yellow,blue,purple
-
ApplicationMedical Equipments, Consumer Electronics ,automotive Electronics Etc.
-
Place of OriginCHINA
-
Brand NameHNL-PCBA
-
CertificationISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000
-
Model NumberPCB Assembly
-
Minimum Order Quantity1 PC
-
PriceNegotiable
-
Packaging DetailsESD packaging with carton box
-
Delivery Time1-7days
-
Payment TermsT/T, Western Union, L/C, MoneyGram
-
Supply Ability10,000,000 Point /Day
Finger Gold Low Dk Rapid PCBA , Multilayer RoHS PCB Assembly
ROHS Finger Gold Low Dk Multilayer Rapid PCBA
PCBA Introduction
The standard wording of PCBA is PCB Assembly . PCBA can be understood as a finished circuit board. The essence is PCB and component assembly. PCB is a printed circuit board and a support for electronic components. PCB procurement and patch processing are two different production methods.
Factory Capacity
Factory Capacity
| FACTORY CAPABILITIES | |||
| No. | Items | 2019 | 2020 |
| 1 | HDI Capabilities | HDI ELIC (4+2+4) | HDI ELIC(5+2+5) |
| 2 | Max layer count | 32L | 36L |
| 3 | Board Thickness | Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm | Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm |
| 4 | Min.Hole Size |
Laser 0.075mm Mechnical 0.15 |
Laser 0.05mm Mechnical 0.15 |
| 5 | Min Line Width/Space | 0.035mm/0.035 | 0.030mm/0.030mm |
| 6 | Copper Thickness | 1/3oz-4oz | 1/3oz-6oz |
| 7 | Size Max Panel size | 700x610mm | 700x610mm |
| 8 | Registration Accuracy | +/-0.05mm | +/-0.05mm |
| 9 | Routing Accuracy | +/-0.075mm | +/-0.05mm |
| 10 | Min.BGA PAD | 0.15mm | 0.125mm |
| 11 | Max Aspect Ratio | 10:1 | 10:1 |
| 12 | Bow and Twist | 0.50% | 0.50% |
| 13 | Impedance Control Tolerance | +/-8% | +/-5% |
| 14 | Daily output | 3,000m2 (Max capacity of equipment) | 4,000m2 (Max capacity of equipment) |
| 15 | Surface Finishing | HASL Lead Free /ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD | |
| 16 | Raw Material | FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI | |
PCBA CAPABILITIES
| PCBA Capability | |||
| Material Type | Item | Min | Max |
| PCB | Dimension (length,width,height.mm) | 50*40*0.38 | 600*400*4.2 |
| Material | FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC | ||
| Surface finish | HASL,OSP,Immersion gold,Flash Gold Finger | ||
| Components | Chip&IC | 1005 | 55mm |
| BGA Pitch | 0.3mm | - | |
| QFP Pitch | 0.3mm | - | |
Our service
PCB Design & Layout
PCB Prototyping
PCB Fabrication
Turn Prototype PCB Assembly
PCB Assembly Services
PCBA
Workshop & Equipment
AL-SPI-IA
solder paste printing equipment
wave-soldering
automatic printing equipment
60times magnifying glass
material baking equipment
X-ray welding inspection
Semi-automatic printing equipment
component counting equipment
Online AOI detector
Reflow welding equipment
Mydata welding equipment
PCBA Application
Aprospace ,Auto Industry ,Communication,Indutrial Control ,Medical device ,Smart Home.etc.
Delivery Time
| Product Type | Qty | Normal lead time | Quick-turn lead time |
| SMT+DIP | 1-50 | 1WD-2WD | 8H |
| SMT+DIP | 51-200 | 2WD-3WD | 1.5WD |
| SMT+DIP | 201-2000 | 3WD-4WD | 2WD |
| SMT+DIP | ≥2001 | 4WD-5WD | 3WD |
| PCBA(2-4Layer) | 1-50 | 2.5WD-3.5WD | 1WD |
| PCBA(2-4Layer) | 51-2000 | 5WD-6WD | 2.5WD |
| PCBA(2-4Layer) | ≥2001 | ≥7WD | 5WD |
| PCBA(6-10Layer) | 1-50 | 3WD-4WD | 2.5WD |
| PCBA(6-10Layer) | 51-2000 | 7WD-8WD | 6WD |
| PCBA(10-HDILayer) | 1-50 | 7WD-9WD | 5WD |
| PCBA(10-HDILayer) | 51-2000 | 9WD-11WD | 7WD |
Partners
Common packaging
PCB: Vacuum packaging with carton box
PCBA: ESD packaging with carton box
FAQ
1, What service do you provide?
We provide turnkey solution including PCB fabrication, SMT Process, PCB Assembly,final assembly, Function testing and other value-added service.
2, What is needed for PCB & PCBA quotation?
PCB: Quantity, Gerber file and technic requirements(material,size, surface finish treatment, copper thickness,board thickness).
PCBA: PCB information, BOM,Testing documents.
3, How to keep our product information and design file secret ?
We can sign a NDA effect by customers side local law and promising to keep customers data in high confidential level.
4, What are the main products of your PCB/PCBA services?
Automotive, Medical, Industry Control,IOT,Smart Home,Military.
5, What is your minimum order quantity (MOQ)?
Our MOQ is 1 PCS, sample and mass production all can support.
6.What are the services you can provide ?
One-stop contract manufacturing
A:PCB Assembly;
B:PCB Design & Layout
C:PCBA programming & functional testing;
D:Electronic components purchasing service;
E:Enclosure molding & final assembly with labels,instructions,enclosure, boxes.
7.Whether all PCBA s will be tested before delivery ?
Yes , we will test each piece of PCBA product under your testing methods ,to ensure quality and functionality .
8.Do you provide OEM service ?
Yes ,we offer PCB and PCBA OEM Service , we manufacture the PCB and PCBA products to your design and requirements .
9. Do you accept process materials supplied by clients?
A Yes, we can provide component source, and we also accept component from client
Our services cover all industries and reach all parts of the world.
