Oem Automotive 1oz Rapid Pcba Multilayer Fabricate

Oem Automotive Pcba 1oz FR4 Multilayer Assembly Fabricate Rapid PCBA


Rapid PCBA Introduction


BEIJING HAINA LEAN CO., LTD offers custom Rapid PCBA service to go along with our high quality fabrication and components purchasing. PCB blank board goes through SMT loading, or the entire process of DIP plug-in, then referred to as PCBA. And the standard way of writing in Europe and America is PCB'A.

Our factory is a professional PCB & PCB'A manufacturer which has more than 10years history and focus on circuit board design and layout, 2-46 layers PCB manufacturing, professional FPC production, electronic components procurement service, SMT professional processing, Soldering and Assembly, especially sample, small and bulk orders.




No. Items 2019 2020(updated)
1 HDI Capabilities HDI ELIC (4+2+4) HDI ELIC(5+2+5)
2 Max layer count 32L 48L
3 Board Thickness Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm
4 Min.Hole Size Laser 0.075mm Laser 0.05mm
Mechnical 0.15 Mechnical 0.15
5 Min Line Width/Space 0.035mm/0.035 0.030mm/0.030mm
6 Copper Thickness 1/3oz-4oz 1/3oz-6oz
7 Size Max Panel size 700x610mm 700x610mm
8 Registration Accuracy +/-0.05mm +/-0.05mm
9 Routing Accuracy +/-0.075mm +/-0.05mm
10 Min.BGA PAD 0.15mm 0.125mm
11 Max Aspect Ratio 10:01 10:01
12 Bow and Twist 0.50% 0.50%
13 Impedance Control Tolerance +/-8% +/-5%
14 Daily output 3,000m2 (Max capacity of equipment) 4,000m2 (Max capacity of equipment)
16 Raw Material FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI

Rapid PCBA fabricating process


Oem Automotive 1oz Rapid Pcba Multilayer Fabricate 0

Oem Automotive 1oz Rapid Pcba Multilayer Fabricate 1


Rapid PCBA Lead Time


Product Type Qty Normal lead time Quick-turn lead time
SMT+DIP 1-50 1WD-2WD 8H
SMT+DIP 51-200 2WD-3WD 1.5WD
SMT+DIP 201-2000 3WD-4WD 2WD
SMT+DIP ≥2001 4WD-5WD 3WD
PCBA(2-4Layer) 1-50 2.5WD-3.5WD 1WD
PCBA(2-4Layer) 51-2000 5WD-6WD 2.5WD
PCBA(2-4Layer) ≥2001 ≥7WD 5WD
PCBA(6-10Layer) 1-50 3WD-4WD 2.5WD
PCBA(6-10Layer) 51-2000 7WD-8WD 6WD
PCBA(10-HDILayer) 1-50 7WD-9WD 5WD
PCBA(10-HDILayer) 51-2000 9WD-11WD 7WD


Rapid PCBA's Application Field


Printed circuit boards and PCB Assembly are mainly used for many communication industry ,Aprospace ,Auto Industry ,Communication,Indutrial Control ,Medical device ,Smart Home,consumer electronics ,automotive electronics , audio and video, optoelectronics, robotics, hydroelectric power, aerospace, education, power supply, printer ,Auto Industry ,Smart Home.etc.


Oem Automotive 1oz Rapid Pcba Multilayer Fabricate 2




Oem Automotive 1oz Rapid Pcba Multilayer Fabricate 3

Oem Automotive 1oz Rapid Pcba Multilayer Fabricate 4Oem Automotive 1oz Rapid Pcba Multilayer Fabricate 5



Common packaging


1.PCB: Vacuum packaging with carton box
2.PCBA: ESD packaging with carton box


Oem Automotive 1oz Rapid Pcba Multilayer Fabricate 6



1, What service do you provide?
We provide turnkey solution including PCB fabrication, SMT Process, PCB Assembly,final assembly, Function testing and other value-added service.
2, What is needed for PCB & PCBA quotation?
PCB: Quantity, Gerber file and technic requirements(material,size, surface finish treatment, copper thickness,board thickness).
PCBA: PCB information, BOM,Testing documents.
3, How to keep our product information and design file secret ?
We can sign a NDA effect by customers side local law and promising to keep customers data in high confidential level.
4, What are the main products of your PCB/PCBA services?
Automotive, Medical, Industry Control,IOT,Smart Home,Military.
5, What is your minimum order quantity (MOQ)?
Our MOQ is 1 PCS, sample and mass production all can support.
6.What are the services you can provide ?
One-stop contract manufacturing
PCB Assembly;
PCB Design & Layout
PCBA programming & functional testing;
Electronic components purchasing service;
Enclosure molding & final assembly with labels,instructions,enclosure, boxes.
7.Whether all PCBA s will be tested before delivery ?
Yes , we will test each piece of PCBA product under your testing methods ,to ensure quality and functionality .
8.Do you provide OEM service ?
Yes ,we offer PCB and PCBA OEM Service , we manufacture the PCB and PCBA products to your design and requirements .
9. Do you accept process materials supplied by clients?
A Yes, we can provide component source, and we also accept component from client


Company Information


Haina lean Electronics Co., Ltd is a one-stop EMS supplier integrating PCB design, PCB manufacturing, Component sourcing and PCB assembly.

Here is strong component supply chain and procceurement team. Prototype and mass production are available. Competitive price is for high-quality and services. Exported to worldwide customer in US, Europe, Canada.
