1oz Copper 1.6mm Board Smt Dip Fast Turnkey Pcb Assembly

Products - Rapid PCBA

High Light

1oz copper turnkey pcb assembly
,
1.6mm turnkey pcb assembly
,
dip turnkey pcb assembly
Product Name

Rapid PCBA
Material

FR4 HASL
Copper Thickness

1/3OZ-10OZ
Min. Line Width/spacing

3mil
Board Thickness

1.6mm,also Customed
Min. Hole Size

≥0.03mm
Surface Finishing

HASL, Lead Free HASL, HASL/OSP/ENIG
Solder Mask Color

Green. Blue. Red. Black. White. Etc.
Board Size

Custom As Require
Service

One-stop EMS Service,PCB; PCBA,ODM And OEM
Place of Origin

CHINA
Brand Name

HNL-PCBA
Certification

ISO9001,IS16949, ISO14001,ROHS ,UL, IPC-A ,QC080000
Model Number

PCBA/06
Minimum Order Quantity

1 PC
Price

Negotiable
Packaging Details

ESD packaging with carton box
Delivery Time

1-7days
Payment Terms

T/T, Western Union, L/C, MoneyGram
Supply Ability

10,000,000 Point /Day

1oz Copper 1.6mm Board Smt Dip Fast Turnkey Pcb Assembly

button button

Get Price Contact Now

FR-4 Multilayer Turnkey Assembly 1oz copper Smt Dip Fast Rapid PCBA

Rapid PCBA Introduction

BEIJING HAINA LEAN CO., LTD fabricates Rapid PCBA service to go along with our high quality fabrication and components purchasing, our factory has more than 10years history.

We have profuse experience in manufacturing PCB,owned experienced technical R & D technology team, young and professional sales and customer service team, experienced and professional procurement team and assembly testing team, which make sure the products quality of the pass rate, on-time delivery rate of customer orders.

Rapid PCBA CAPABILITIES

Base material	FR4,High-TG FR4,CEM3,aluminum, High frequency(Rogers,Taconic,Aron,PTFE,)
Layers	1-46
Copper Thickness	0.3oz,0.5oz, 1oz, 2oz, 3oz,4oz,5oz, 6oz
Dielectric Thickness	0.05mm, 0.075mm, 0.1mm,0.15mm,0.2mm
board Core Thickness	0.4mm,0.6mm, 0.8mm, 1.0mm, 1.2mm,
board Core Thickness	1.5mm, 2.0mm, 3.0mm and 3.2mm
Board Thickness	0.3mm - 4.0mm
Thickness Tolerance	+/-10%
Surface Finishing	HASL lead free,ENIG,Plated Gold,Immersion Gold,OSP
Solder Mask Color	Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue
Legend Color	Black, White etc
Assembly Types	Surface mount
	Thro-hole
	Mixed technology (SMT & Thru-hole)
	Single or double sided placement
	Conformal coating
	Shield cover assembly for EMI emission control
Parts Procurement	Full Turnkey, Partial Turnkey, Kitted / Consigned
Component types	SMT 01005 or larger
	BGA 0.4mm pitch, POP (Package on Package)
	WLCSP 0.35mm pitch
	Hard metric connectors
	Cable & wire
Other Techniques	Free DFM Review
	Box Build Assembly
	100% AOI test and X-ray test for BGA
	Components cost-down
	Function test as custom
	Protection technology

PCBA Capability
Material Type	Item	Min	Max
PCB	Dimension (length,width,height.mm)	50400.38	6004004.2
Components	Chip&IC	1005	55mm
	BGA Pitch		-
	QFP Pitch		-

Rapid PCBA fabricating process

1oz Copper 1.6mm Board Smt Dip Fast Turnkey Pcb Assembly 0

1oz Copper 1.6mm Board Smt Dip Fast Turnkey Pcb Assembly 1

1oz Copper 1.6mm Board Smt Dip Fast Turnkey Pcb Assembly 2

Rapid PCBA Lead Time

Product Type	Qty	Normal lead time	Quick-turn lead time
SMT+DIP	1-50	1WD-2WD	8H
SMT+DIP	51-200	2WD-3WD	1.5WD
SMT+DIP	201-2000	3WD-4WD	2WD
SMT+DIP	≥2001	4WD-5WD	3WD
PCBA(2-4Layer)	1-50	2.5WD-3.5WD	1WD
PCBA(2-4Layer)	51-2000	5WD-6WD	2.5WD
PCBA(2-4Layer)	≥2001	≥7WD	5WD
PCBA(6-10Layer)	1-50	3WD-4WD	2.5WD
PCBA(6-10Layer)	51-2000	7WD-8WD	6WD
PCBA(10-HDILayer)	1-50	7WD-9WD	5WD
PCBA(10-HDILayer)	51-2000	9WD-11WD	7WD

Rapid PCBA's Application Field

Printed circuit boards and PCB Assembly are mainly used for many communication industry ,Aprospace ,Auto Industry ,Communication,Indutrial Control ,Medical device ,Smart Home,consumer electronics ,automotive electronics , audio and video, optoelectronics, robotics, hydroelectric power, aerospace, education, power supply, printer ,Auto Industry ,Smart Home.etc.

1oz Copper 1.6mm Board Smt Dip Fast Turnkey Pcb Assembly 3

Workshop

1oz Copper 1.6mm Board Smt Dip Fast Turnkey Pcb Assembly 4

Common packaging

1.PCB: Vacuum packaging with carton box
2.PCBA: ESD packaging with carton box

1oz Copper 1.6mm Board Smt Dip Fast Turnkey Pcb Assembly 6

FAQ

1.What are needed for quotation?
PCB: Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ......)
PCBA: PCB information, BOM, (Testing documents...)

2. What file formats do you accept for production?
Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)

3.Are my files safe?
Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third party.

4.MOQ?
There is no MOQ .We can flexibly handle small and mass production.

5.Shipping Cost ?

The shipping cost is determined by the destination ,weight ,packing size of the goods .We can provide shipping, air, land, express and other transportation services .

6.How to ensure high-quality production?
The process is strictly controlled under ISO 9001:2015 standards.
Most of our advanced equipment and tools are imported from abroad. Such as Flying Probe, X-ray Inspection, AOI (Automated Optical Inspector) and ICT (in-circuit testing).
We have a very professional QC team.

1oz Copper 1.6mm Board Smt Dip Fast Turnkey Pcb Assembly 7
