OEM ISO Medical PCB Assembly , Infrared Thermometer SMT PCB Assembly

OEM ISO Medical PCB Assembly , Infrared Thermometer SMT PCB Assembly

  • High Light

    ISO Medical PCB Assembly

    ,

    OEM Medical PCB Assembly

    ,

    0.3mm SMT PCB Assembly

  • Product Name
    Medical PCB Assembly
  • Layers
    1-36 Layers (Custom)
  • Copper Thickness
    0.3oz -6oz
  • Min. Line Spacing
    0.030mm
  • Board Thickness
    0.3mm - 3.5mm
  • Min. Hole Size
    Laser 0.05mm ; Mechnical 0.15
  • Surface Treatment
    HASL,OSP,ENIG,HASL Lead Free,Immersion Gold
  • Solder Mask Color
    Green,white,black,red,orange,yellow,blue,purple
  • Material
    FR-4,High Tg FR-4, Halogen Free FR-4, Thick Copper FR-4, Aluminium Based, Rogers, Taconic
  • Application
    Medical Equipments, Consumer Electronics ,automotive Electronics Etc.
  • Place of Origin
    CHINA
  • Brand Name
    HNL-PCBA
  • Certification
    ISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000
  • Model Number
    Medical PCB Assembly
  • Minimum Order Quantity
    1 PC
  • Price
    Negotiable
  • Packaging Details
    ESD packaging with carton box
  • Delivery Time
    1-7days
  • Payment Terms
    T/T, Western Union, L/C, MoneyGram
  • Supply Ability
    10,000,000 Point /Day

OEM ISO Medical PCB Assembly , Infrared Thermometer SMT PCB Assembly

OEM ISO Infrared Thermometer SMT Medical PCB Assembly

Medical PCB Assembly Introduction



During the viral period, the frequency band of the ventilator product is lacking. As an effective means to artificially replace the autonomous ventilation function, the ventilator has been widely used for respiratory failure caused by various reasons, anesthesia respiratory management during major surgery, and respiratory support Treatment and emergency resuscitation occupy a very important position in the field of modern medicine. The ventilator is a vital medical device that can prevent and treat respiratory failure, reduce complications, save and extend the life of patients.



PCB CAPABILITIES



FACTORY CAPABILITIES
No. Items 2019 2020
1 HDI Capabilities HDI ELIC (4+2+4) HDI ELIC(5+2+5)
2 Max layer count 32L 36L
3 Board Thickness Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm
4 Min.Hole Size

Laser 0.075mm

Mechnical 0.15

Laser 0.05mm

Mechnical 0.15

5 Min Line Width/Space 0.035mm/0.035 0.030mm/0.030mm
6 Copper Thickness 1/3oz-4oz 1/3oz-6oz
7 Size Max Panel size 700x610mm 700x610mm
8 Registration Accuracy +/-0.05mm +/-0.05mm
9 Routing Accuracy +/-0.075mm +/-0.05mm
10 Min.BGA PAD 0.15mm 0.125mm
11 Max Aspect Ratio 10:1 10:1
12 Bow and Twist 0.50% 0.50%
13 Impedance Control Tolerance +/-8% +/-5%
14 Daily output 3,000m2 (Max capacity of equipment) 4,000m2 (Max capacity of equipment)
15 Surface Finishing HASL Lead Free /ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD
16 Raw Material FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI



PCBA CAPABILITIES



PCBA Capability
Material Type Item Min Max
PCB Dimension (length,width,height.mm) 50*40*0.38 600*400*4.2
Material FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC
Surface finish HASL,OSP,Immersion gold,Flash Gold Finger
Components Chip&IC 1005 55mm
BGA Pitch 0.3mm -
QFP Pitch 0.3mm -





Medical PCB Assembly Technologies


1.Multi-layer / High Density Interconnect (HDI) PCBs ; 2.THT (Through-Hole Technology );
3.Flex & Rigid-Flex ;        4.SMT & mini SMT ;              5. BGA techonology ;

6.Reflow Soldering ;        7.Wave-soldering ;                8.Conformal Coating ;etc.


Our service



1.PCB Design & Layout     2.PCB Prototyping             3.PCB Fabrication              4.Turn Prototype PCB Assembly
5.PCB Assembly Service   6.Contract PCB Assembly  7.Trunkey PCB Assembly  8.Components sourcing,

9.Function test                  10.conformal coating           11.complete assembly

OEM ISO Medical PCB Assembly , Infrared Thermometer SMT PCB Assembly 0



Workshop & Equipment


Our assembly process has been designed to meet all variations of PCBs, including single- or double-sided boards, Multilayer , rigid ,flexible circuits and Mixed technology. We run both leaded and RoHS/Lead-Free Surface Mount Technology (SMT) lines as well as wave solder equipment for both RoHS and leaded processes. Our manufacturing process allows for the highest quality product through process automation, environmental controls, automatic optical inspection (AOI) and flying probe at the best competitive price.



OEM ISO Medical PCB Assembly , Infrared Thermometer SMT PCB Assembly 1


OEM ISO Medical PCB Assembly , Infrared Thermometer SMT PCB Assembly 2

OEM ISO Medical PCB Assembly , Infrared Thermometer SMT PCB Assembly 3



OEM ISO Medical PCB Assembly , Infrared Thermometer SMT PCB Assembly 4OEM ISO Medical PCB Assembly , Infrared Thermometer SMT PCB Assembly 5



Contract PCB Assembly Application



Printed circuit boards And PCB Assembly are mainly used for many communication industry, medical equipments, consumer electronics ,automotive electronics , audio and video, optoelectronics, robotics, hydroelectric power, aerospace, education, power supply, printer ,Auto Industry ,Smart Home.etc.

OEM ISO Medical PCB Assembly , Infrared Thermometer SMT PCB Assembly 6



Delivery Time



Product Type Qty Normal lead time Quick-turn lead time
SMT+DIP 1-50 1WD-2WD 8H
SMT+DIP 51-200 2WD-3WD 1.5WD
SMT+DIP 201-2000 3WD-4WD 2WD
SMT+DIP ≥2001 4WD-5WD 3WD
PCBA(2-4Layer) 1-50 2.5WD-3.5WD 1WD
PCBA(2-4Layer) 51-2000 5WD-6WD 2.5WD
PCBA(2-4Layer) ≥2001 ≥7WD 5WD
PCBA(6-10Layer) 1-50 3WD-4WD 2.5WD
PCBA(6-10Layer) 51-2000 7WD-8WD 6WD
PCBA(10-HDILayer) 1-50 7WD-9WD 5WD
PCBA(10-HDILayer) 51-2000 9WD-11WD 7WD



Partner



OEM ISO Medical PCB Assembly , Infrared Thermometer SMT PCB Assembly 7



Company introduce



Beijing Haina lean Electronics Co.,Ltd is one of the most professional PCB manufacture in Beijing,China. With more then 10 years of development, Haina Lean Electronics turns into a first class manufacture of HDI PCB ,with production capability 4000 square meters.

Our factory is providing high quality bare PCB, PCB layout design service and PCB assembly service,including components sourcing, function test,conformal coating and complete assembly for clients all.



We have profuse experience in manufacturing PCB,owned experienced technical R & D technology team, young and professional sales and customer service team, experienced and professional procurement team and assembly testing team, which make sure the products quality of the pass rate, on-time delivery rate of customer orders.

Our services include: circuit board design and layout, 2-46 layers PCB manufacturing, professional FPC production, electronic components purchasing, SMT professional processing, Soldering and Assembly, especially sample and small bulk orders. we have the advantages of a quick quote, fast production, fast delivery.



The company pursues "inclusiveness, excellence, people-oriented". Constantly innovate, take technology as the core, regard quality as life, and wholeheartedly provide customers with high-quality and high-efficiency humanized services.We are willing to serve our customers with the principle of continuous honesty & trustworthiness, pragmatism and innovation.
