IPC BGA Prototype Electronic PCB Assembly

IPC BGA Prototype Electronic PCB Assembly

  • High Light

    IPC Prototype Electronic PCB Assembly

    ,

    BGA Prototype Electronic PCB Assembly

    ,

    0.56oz BGA PCB Assembly

  • Product Name
    PCB Assembly
  • Copper Thickness
    0.3. 0.56 ..... 6oz
  • Layers
    1-36 Layers
  • Max Board Size
    700x610mm
  • Min. Line Spacing
    0.030mm
  • Board Thickness
    0.3-3.5mm
  • Min. Line Width
    0.03mm
  • Min. Hole Size
    Laser 0.05mm
  • Material
    FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI
  • Surface Finishing
    HASL,OSP,ENIG,HASL Lead Free,Immersion Gold
  • Solder Mask Color
    Blue.green.red.black.white.etc
  • Pcb Assembly Method
    Mixed,BGA,SMT,Through-hole
  • Service
    One-stop Service, PCB Design ,PCBA , ODM And OEM
  • Application
    Medical Products ,Office Equipment,Household Appliances,Automotive Electronics, Digital Electronics, Aerospace Products, Communication Electronics, Industrial Control, Elevator, High Speed Railway, Digital TV, Satellite, Radar,Video Processin G, Gateway
  • Place of Origin
    CHINA
  • Brand Name
    HNL-PCBA
  • Certification
    ISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000
  • Model Number
    PCB Assembly
  • Minimum Order Quantity
    1 PC
  • Price
    Negotiable
  • Packaging Details
    ESD packaging with carton box
  • Delivery Time
    1-7days
  • Payment Terms
    T/T, Western Union, L/C, MoneyGram
  • Supply Ability
    10,000,000 Point /Day

IPC BGA Prototype Electronic PCB Assembly

 IPC standard BGA PCB Assembly for automotive electronics



PCBA Assembly Introduction

PCBA is a finished board. it is divided into 4 layers, 6 layers 8 lavers and other multilayer , and the most common are 4 laver and 6 laver PCBs.

PCBA is the circuit board plug-in assembly, added SMT and DIP process. (PCBA=Printed Circuit Board +Assembly)
In other words, the PCB board goes through the SMT and then goes through the entire process of the DIP plug-in, abbreviated as PCBA.



PCB CAPABILITIES



FACTORY CAPABILITIES
No. Items 2019 2020
1 HDI Capabilities HDI ELIC (4+2+4) HDI ELIC(5+2+5)
2 Max layer count 32L 36L
3 Board Thickness Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm
4 Min.Hole Size

Laser 0.075mm

Mechnical 0.15

Laser 0.05mm

Mechnical 0.15

5 Min Line Width/Space 0.035mm/0.035 0.030mm/0.030mm
6 Copper Thickness 1/3oz-4oz 1/3oz-6oz
7 Size Max Panel size 700x610mm 700x610mm
8 Registration Accuracy +/-0.05mm +/-0.05mm
9 Routing Accuracy +/-0.075mm +/-0.05mm
10 Min.BGA PAD 0.15mm 0.125mm
11 Max Aspect Ratio 10:1 10:1
12 Bow and Twist 0.50% 0.50%
13 Impedance Control Tolerance +/-8% +/-5%
14 Daily output 3,000m2 (Max capacity of equipment) 4,000m2 (Max capacity of equipment)
15 Surface Finishing HASL Lead Free /ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD
16 Raw Material FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI



PCBA CAPABILITIES



PCBA Capability
Material Type Item Min Max
PCB Dimension (length,width,height.mm) 50*40*0.38 600*400*4.2
Material FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC
Surface finish HASL,OSP,Immersion gold,Flash Gold Finger
Components Chip&IC 1005 55mm
BGA Pitch 0.3mm -
QFP Pitch 0.3mm -



PCBA Assembly Process

PCB Loading , Solder paste printing ,surface mounting , Reflow soldering , DIP Soldering ,Wave soldering ,AOI ,X ray ,First article inspection ,QC ,Package ,Shipping .



IPC BGA Prototype Electronic PCB Assembly



Our services include



PCB Design
PCB Fabrication
PCBA Assembly
Components Sourcing
Function Testing
Enclosure/box/finished Assembly



IPC BGA Prototype Electronic PCB Assembly



Delivery Time



Product Type Qty Normal lead time Quick-turn lead time
SMT+DIP 1-50 1WD-2WD 8H
SMT+DIP 51-200 2WD-3WD 1.5WD
SMT+DIP 201-2000 3WD-4WD 2WD
SMT+DIP ≥2001 4WD-5WD 3WD
PCBA(2-4Layer) 1-50 2.5WD-3.5WD 1WD
PCBA(2-4Layer) 51-2000 5WD-6WD 2.5WD
PCBA(2-4Layer) ≥2001 ≥7WD 5WD
PCBA(6-10Layer) 1-50 3WD-4WD 2.5WD
PCBA(6-10Layer) 51-2000 7WD-8WD 6WD
PCBA(10-HDILayer) 1-50 7WD-9WD 5WD
PCBA(10-HDILayer) 51-2000 9WD-11WD 7WD



PCBA Assembly Application Field



Medical Products ,Office Equipment,Household Appliances,Automotive electronics, digital electronics,

aerospace products, communication electronics, industrial control, elevator, high speed railway, digital TV,

satellite, radar,Video processing, Gateway control ,Network devices ,etc



IPC BGA Prototype Electronic PCB Assembly



Partners



IPC BGA Prototype Electronic PCB Assembly



Common packaging


PCB: Vacuum packaging with carton box
PCBA: ESD packaging with carton box



IPC BGA Prototype Electronic PCB Assembly



Certification



IPC BGA Prototype Electronic PCB Assembly







FAQ



Q1.What are needed for quoation ?

PCB :Gerber File (Protel.Power PCB ,PADs File)
PCBA: Gerber File and BOM

Q2.What file formats do you accept for production ?

Gerber file :CAM350 RS274X
PCB File:protel 99SE ,P-CAD 2001 PCB
BOM:Excel (PDF,Word ,txt)

Q3.Are my files safe ?

Your files are held in complete safety and security ,we protect the intellectual property for our customers in the whole process .All documents from customer are never shared with any third parties .

Q4.What's your MOQ ?

No Moq ,We accept small orders as well as mass production

Q5.Shipping Cost ?

The shipping cost is determined by the destination ,weight ,packing size of the goods .We can provide shipping, air, land, express and other transportation services .

Q6.Can You provide fast rotating PCB ?

Yes , we can provide fast service 24 hours .

Q7.What are the services you can provide ?

One-stop contract manufacturing
A:PCB Assembly;
B:PCB Design & Layout
C:PCBA programming & functional testing;
D:Electronic components purchasing service;
E:Enclosure molding & final assembly with labels,instructions,enclosure, boxes.

Q8.Whether all PCBA s will be tested before delivery ?

Yes , we will test each piece of PCBA product under your testing methods ,to ensure quality and functionality .

Q9.Do you provide OEM service ?

Yes ,we offer PCB and PCBA OEM Service , we manufacture the PCB and PCBA products to your design and requirements .



Company Information



Haina lean Electronics Co., Ltd is a one-stop EMS supplier integrating PCB design, PCB manufacturing, Component sourcing and PCB assembly.

Our company was established in May 1, 2012 in Beijing. And expansion was completed in June 2016. The company is specialized in electronic products supporting processing services, mainly to undertake circuit board design, layout production, components procurement, PCB plate making, circuit board welding assembly debugging and other OEM/ODM services.



Our first factory is located in Changping District, Beijing, the main radiation Haidian, Changping, Chaoyang three areas of Beijing. Since our company’s establishment, we have been adhering to creating high quality, high efficiency, low-cost business philosophy based on the circuit board processing industry for customers. Most of the key staff of the company are mature technical talents who have been engaged in the industry for more than 10 years, and have rich experience in the production of SMT and DIP, also has rich experience in production for high density & difficulty to package components such as BGA. The factory covers an area of 1500 square meters. Since its establishment, we obtain a good reputation in the industry through the continuous efforts of all staff and high quality service . Our second branch plant is located in Langfang city, and mainly cover Fengtai and Daxing Yizhuang area.



The company pursues "inclusiveness, excellence, people-oriented". Constantly innovate, take technology as the core, regard quality as life, and wholeheartedly provide customers with high-quality and high-efficiency humanized services.We are willing to serve our customers with the principle of continuous honesty & trustworthiness, pragmatism and innovation.



At present, the main cooperation industries are automotive electronics, communications, audio and video, optoelectronics, robotics, hydroelectric power, medical care, aerospace, education, radio frequency, power supply, printer etc industries.
