HASL OEM Communication Solution SMT PCB Assembly



PCBA Manufacturer Introduction

Haina Lean Electronics Company is a professional manufacturer of printed circuit board. And is strong, trustworthy, abiding by contracts, guarantee our products' quality. The main products are PCB Layout, PCB design and PCBA (PCB'A) and enjoy a high position amony consumers. Ensure your timeliness, professional material proceurement team and fast warehouse. Haina Lean Electronics is your Trusted PCB Assembly Partner.



Our products are mainly exported to Europe and USA. Our customers spread over more than 80 countries. Products are widely used in various industries. many retailers and agents worldwide.



PCB CAPABILITIES



Assembly Types: Surface mount, Thro-hole, Mixed technology (SMT & Thru-hole), Single or double sided placement, Conformal coating, Shield cover assembly for EMI emission control



FACTORY CAPABILITIES
No.	Items	2019	2022
1	HDI Capabilities	HDI ELIC (4+2+4)	HDI ELIC(5+2+5)
2	Max layer count	32L	36L
3	Board Thickness	Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm	Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm
4	Min.Hole Size	Laser 0.075mm Mechnical 0.15	Laser 0.05mm Mechnical 0.15
5	Min Line Width/Space	0.035mm/0.035	0.030mm/0.030mm
6	Copper Thickness	1/3oz-4oz	1/3oz-6oz
7	Size Max Panel size	700x610mm	700x610mm
8	Registration Accuracy	+/-0.05mm	+/-0.05mm
9	Routing Accuracy	+/-0.075mm	+/-0.05mm
10	Min.BGA PAD	0.15mm	0.125mm
11	Max Aspect Ratio	10:1	10:1
12	Bow and Twist	0.50%	0.50%
13	Impedance Control Tolerance	+/-8%	+/-5%
14	Daily output	3,000m2 (Max capacity of equipment)	4,000m2 (Max capacity of equipment)
15	Surface Finishing	HASL Lead Free /ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD
16	Raw Material	FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI



PCBA CAPABILITIES



PCBA Capability
Material Type	Item	Min	Max
PCB	Dimension (length,width,height.mm)	50*40*0.38	600*400*4.2
	Material	FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC
	Surface finish	HASL,OSP,Immersion gold,Flash Gold Finger
Components	Chip&IC	1005	55mm
	BGA Pitch	0.3mm	-
	QFP Pitch	0.3mm	-



Our advantage



Service value

Independent quotation system to quickly serve the market



PCB manufacturing

High-tech PCB and PCB assembly production line



Material purchasing

A team of experienced electronic component procurement engineers



SMT post soldering

Dust-free workshop, high-end SMT patch processing



Why choose us?



Welcome to visit our factory, Haina lean Electronics Co., Ltd.
1. Experienced: Focus on PCB And PCBA munufacturing over 10 years.
2. Professional: Expertise engineer with barrier-free English
3. Rapid delivery: On-time delivery rate reaches 98%
4.Cost effective: No excessive profits. Lower cost with same quality And service







Delivery Time



Product Type	Qty	Normal lead time	Quick-turn lead time
SMT+DIP	1-50	1WD-2WD	8H
SMT+DIP	51-200	2WD-3WD	1.5WD
SMT+DIP	201-2000	3WD-4WD	2WD
SMT+DIP	≥2001	4WD-5WD	3WD
PCBA(2-4Layer)	1-50	2.5WD-3.5WD	1WD
PCBA(2-4Layer)	51-2000	5WD-6WD	2.5WD
PCBA(2-4Layer)	≥2001	≥7WD	5WD
PCBA(6-10Layer)	1-50	3WD-4WD	2.5WD
PCBA(6-10Layer)	51-2000	7WD-8WD	6WD
PCBA(10-HDILayer)	1-50	7WD-9WD	5WD
PCBA(10-HDILayer)	51-2000	9WD-11WD	7WD



PCBA Manufacturer Application Field



Our PCB SMT Assembly Military-Industrial Sphere ,Automotive /automobile , Medical .Communication Solution, Industrial Control, Aerospace , Image Processing ,video Processing Technology ,smart Home ,securit Etc.







Workshop

The company is equipped with advanced production lines, such as the latest models from Japan’s YAMAHA, South Korea’s Samsung ,HELLER ,GKG-G5 ,AOI ,X-RAY,Online solder paste inspection/SPI machine ,Desen automatic screen printing machine and so on.
10 SMT high-speed production lines,

4 DIP production lines,
2 finished assembly lines.





Partners





Common packaging

PCB: Vacuum packaging with carton box
PCBA: ESD packaging with carton box





Certification







FAQ



FAQ

Q1.What are needed for quotation?
PCB: Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ......)
PCBA: PCB information, BOM, (Testing documents...)

Q2. What file formats do you accept for production?
Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)

Q3.Are my files safe?
Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third party.

Q4.MOQ?
There is no MOQ .We can flexibly handle small and mass production.

Q5.Shipping Cost ?

The shipping cost is determined by the destination ,weight ,packing size of the goods .We can provide shipping, air, land, express and other transportation services .

Q6.How to ensure high-quality production?
The process is strictly controlled under ISO 9001:2015 standards.
Most of our advanced equipment and tools are imported from abroad. Such as Flying Probe, X-ray Inspection, AOI (Automated Optical Inspector) and ICT (in-circuit testing).
We have a very professional QC team.

Q7.What are the services you can provide ?

One-stop contract manufacturing
A:PCB Assembly;
B:PCB Design & Layout
C:PCBA programming & functional testing;
D:Electronic components purchasing service;
E:Enclosure molding & final assembly with labels,instructions,enclosure, boxes.
Q8.Whether all PCBA s will be tested before delivery ?

Yes , we will test each piece of PCBA product under your testing methods ,to ensure quality and functionality .

Q9.Do you provide OEM service ?

Yes ,we offer PCB and PCBA OEM/ODM Service , produce the PCB and PCBA products as your design and requirements .
