0.3oz Hasl Surface Mount Pcb Assembly Electronic Circuit Board

0.3oz Hasl Surface Mount Pcb Assembly Electronic Circuit Board

  • High Light

    0.3oz surface mount pcb assembly

    ,

    hasl surface mount pcb assembly

    ,

    hasl smt pcb assembly

  • Product Name
    PCB SMT Assembly
  • Material
    FR4
  • Copper Thickness
    0.3OZ, 0.6, 1, ...... 6OZ
  • Min. Line Width/spacing
    0.030mm
  • Min. Hole Size
    Laser 0.05mm ; Mechnical 0.15
  • Surface Finishing
    HASL Lead Free
  • Solder Mask Color
    Green. Red. Blue. White. Black.Yellow Etc.
  • PCB'A Process
    SMT, DIP, THT; Mixed
  • Layers
    1-48
  • Pcb Standard
    IPC-A-610 E,IPC-II Standard
  • Place of Origin
    CHINA
  • Brand Name
    HNL-PCBA
  • Certification
    ISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000
  • Model Number
    PCB Assembly 04
  • Minimum Order Quantity
    1 PC
  • Price
    Negotiable
  • Packaging Details
    ESD packaging with carton box
  • Delivery Time
    1-10days
  • Payment Terms
    T/T, Western Union, L/C, MoneyGram
  • Supply Ability
    10,000,000 Point /Day

0.3oz Hasl Surface Mount Pcb Assembly Electronic Circuit Board

HASL 0.3oz Surface Mount Pcb Assembly Electronic Circuit PCB SMT Assembly



PCB SMT Assembly Introduction

SMT development trend: 1. Higher process stability and reliability to meet mass production, professional production, reduce costs. 2. Higher assembly precision, to meet the micro-spacing device mounting, improve assembly density. 3. Higher technical content, adapt to the assembly of new device packaging. 4. It is conducive to environmental protection and human health.

We are devoted to PCBA one-step EMS in large quantities. Be the most professional PCBA servicer and manufacturer, One glance and you'll know you have found the right manufacturing partner!

We offer competitive pricing, as well as flexible shipment plans to you. Our engineers is qualified and experienced in producing surface-mount (SMT), through-hole (THT) and mixed-technology components and fine-pitch parts and ball grid arrays (BGAs) for high-density FR-4 PCBs .



PCB CAPABILITIES





Layers 1 - 46 L (Custom )
Substrate FR-4,CTI600,Tg180,,Anti CAF,Halogen-free,,High frequency,Tg170&HF
Max. panel size 700x610mm (Custom)
Board thickness 0.3 mm - 3.5 mm.
Copper thickness 1/3 oz. to 6 oz. (outer) (Max)
Hole > 0.15mm.
Aspect Ratio 10 : 1
Min. track width 3.0 mils(partial)
Min. track space 3.0mils(partial)
Min. S/M bridge 3mil
Hole plugging diameter 0.3 mm~0.55 mm.
Impedance tolerance +/- 10%.
Color of S/M green,white,black,red,orange,yellow,blue,purple
Surface treatment OSP,HAL,HAL LF,ENIG,Hard gold,Imm Ag,Imm Sn,Peelable soldermask,Carbon ink print,Selective hard gold


PCBA CAPABILITIES



PCBA Capability
Material Type Item Min Max
PCB Dimension (length,width,height.mm) 50*40*0.38 600*400*4.2
Material FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC
Surface finish HASL,OSP,Immersion gold,Flash Gold Finger
Components Chip&IC 1005 55mm
BGA Pitch 0.3mm -
QFP Pitch 0.3mm -



Our SMT capabilities:



SMT Assembly: SMT provides a flexible high technology.

7 high-speed placement machines,

7 automatic printers with fiducial alignment,

2 X-ray machines,

BGA maintenance machines,

ICT test machines



PCB SMT Assembly Process



1.Solder Paste stenciling---2.Surface Mount Technology (Pick and Place)---3.Reflow Soldering---4.Inspection and Quality Control---5.Through-Hole Component Insertion (DIP Process)---6.Final Inspection and Functional Test

0.3oz Hasl Surface Mount Pcb Assembly Electronic Circuit Board 0



Our advantage:



1.Service value

Independent quotation system to quickly serve the market

2.PCB manufacturing

High-tech PCB and PCB assembly production line

3.Material purchasing

A team of experienced electronic component procurement engineers

4.SMT post soldering

Dust-free workshop, high-end SMT patch processing



0.3oz Hasl Surface Mount Pcb Assembly Electronic Circuit Board 1

0.3oz Hasl Surface Mount Pcb Assembly Electronic Circuit Board 2



PCB SMT Assembly Delivery Time



Product Type Qty Normal lead time Quick-turn lead time
SMT+DIP 1-50 1WD-2WD 8H
SMT+DIP 51-200 2WD-3WD 1.5WD
SMT+DIP 201-2000 3WD-4WD 2WD
SMT+DIP ≥2001 4WD-5WD 3WD
PCBA(2-4Layer) 1-50 2.5WD-3.5WD 1WD
PCBA(2-4Layer) 51-2000 5WD-6WD 2.5WD
PCBA(2-4Layer) ≥2001 ≥7WD 5WD
PCBA(6-10Layer) 1-50 3WD-4WD 2.5WD
PCBA(6-10Layer) 51-2000 7WD-8WD 6WD
PCBA(10-HDILayer) 1-50 7WD-9WD 5WD
PCBA(10-HDILayer) 51-2000 9WD-11WD 7WD



PCB SMT Assembly Application Field



Our products are widely used in

1.communication equipment,

2.industrial control,

3.consumer electronics,

4.medical equipment,

5.aerospace,

6.light-emitting diode lighting,

7.automotive electronics etc.



0.3oz Hasl Surface Mount Pcb Assembly Electronic Circuit Board 3



Workshop



0.3oz Hasl Surface Mount Pcb Assembly Electronic Circuit Board 40.3oz Hasl Surface Mount Pcb Assembly Electronic Circuit Board 5

0.3oz Hasl Surface Mount Pcb Assembly Electronic Circuit Board 6



Common packaging



1.PCB: Vacuum packaging with carton box
2.PCBA: ESD packaging with carton box



0.3oz Hasl Surface Mount Pcb Assembly Electronic Circuit Board 7



FAQ



1.What are needed for quotation?
PCB: Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ......)
PCBA: PCB information, BOM, (Testing documents...)

2. What file formats do you accept for production?
Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)

3.Are my files safe?
Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third party.

4.MOQ?
There is no MOQ .We can flexibly handle small and mass production.

5.Shipping Cost ?

The shipping cost is determined by the destination ,weight ,packing size of the goods .We can provide shipping, air, land, express and other transportation services .

6.How to ensure high-quality production?
The process is strictly controlled under ISO 9001:2015 standards.
Most of our advanced equipment and tools are imported from abroad. Such as Flying Probe, X-ray Inspection, AOI (Automated Optical Inspector) and ICT (in-circuit testing).
We have a very professional QC team.



0.3oz Hasl Surface Mount Pcb Assembly Electronic Circuit Board 8
