Double Side 3oz Immersion Gold Automotive Circuit Board Pcb

Double Side 3oz Immersion Gold Automotive Circuit Board Pcb

  • High Light

    3oz automotive circuit board

    ,

    immersion gold automotive circuit board

    ,

    3oz automotive pcb

  • Product Name
    Automotive PCBA Manufacturing
  • Layers
    Double Side ,Multilayer (Custom)
  • Copper Thickness
    1oz 2oz 3oz ...
  • Min. Line Spacing
    0.030mm/0.030mm
  • Board Thickness
    0.3.0.6.1.2 1.6 ......3.5mm
  • Min. Hole Size
    Laser 0.05mm ; Mechnical 0.15
  • Solder Mask Color
    Green, White,Black. Blue(Customized)
  • Material
    FR4 /Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI
  • Surface Finishing
    HASL,OSP,ENIG,HASL Lead Free,Immersion Gold
  • Application
    Communication Industry, Power, Security, Optoelectronics, Industrial Control, Medical Equipments, Consumer Electronics And Automobile Industry Etc Field.
  • Place of Origin
    CHINA
  • Brand Name
    HNL-PCB
  • Certification
    ISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000
  • Model Number
    Automotive PCBA
  • Minimum Order Quantity
    1 PC
  • Price
    Negotiable
  • Packaging Details
    ESD packaging with carton box
  • Delivery Time
    1-7days
  • Payment Terms
    T/T, Western Union, L/C, MoneyGram
  • Supply Ability
    10,000,000 Point /Day

Double Side 3oz Immersion Gold Automotive Circuit Board Pcb

FR-4 Immersion Gold HDI craft Automotive PCBA

Automotive PCBA  Introduction



Haina Lean owns the entire process from component procurement to PCB assembly. Our advanced QA process verifies that every PCBA is manufactured with the highest quality. Turnkey PCB assembly and manufacturing is the best solution for engineers who have urgent and highly complex projects and want to avoid project management problems.



Factory Capabilities



FACTORY CAPABILITIES
No. Items 2019 2020
1 HDI Capabilities HDI ELIC (4+2+4) HDI ELIC(5+2+5)
2 Max layer count 32L 36L
3 Board Thickness Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm
4 Min.Hole Size Laser 0.075mm Laser 0.05mm
Mechnical 0.15mm Mechnical 0.15mm
5 Min Line Width/Space 0.035mm/0.035mm 0.030mm/0.030mm
6 Copper Thickness 1/3oz-4oz 1/3oz-6oz
7 Size Max Panel size 700x610mm 700x610mm
8 Registration Accuracy +/-0.05mm +/-0.05mm
9 Routing Accuracy +/-0.075mm +/-0.05mm
10 Min.BGA PAD 0.15mm 0.125mm
11 Max Aspect Ratio 10:1 10:1
12 Bow and Twist 0.50% 0.50%
13 Impedance Control Tolerance +/-8% +/-5%
14 Daily Output 3,000m2 (Max capacity of equipment) 4,000m2 (Max capacity of equipment)
15 Surface Finishing ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD
16 Raw Material FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI



PCBA CAPABILITIES



PCBA Capability
Material Type Item Min Max
PCB Dimension (length,width,height.mm) 50*40*0.38 600*400*4.2
Material FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC
Surface finish HASL,OSP,Immersion gold,Flash Gold Finger
Components Chip&IC 1005 55mm
BGA Pitch 0.3mm -
QFP Pitch 0.3mm -



PCB Assembly Craftsmanship



Our assembly process has been designed to meet all variations of PCBs, including single- or double-sided boards, Multilayer , rigid ,flexible circuits and Mixed technology. We run both leaded and RoHS/Lead-Free Surface Mount Technology (SMT) lines as well as wave solder equipment for both RoHS and leaded processes. Our manufacturing process allows for the highest quality product through process automation, environmental controls, automatic optical inspection (AOI) and flying probe at the best competitive price.



Double Side 3oz Immersion Gold Automotive Circuit Board Pcb 0


Our service



Double Side 3oz Immersion Gold Automotive Circuit Board Pcb 1



PCBA Application Field

Printed circuit boards and PCB Assembly are widey used in many communication industry, power, security, optoelectronics, industrial control, medical equipments, consumer electronics and automobile industry etc field.



Double Side 3oz Immersion Gold Automotive Circuit Board Pcb 2



Workshop


Double Side 3oz Immersion Gold Automotive Circuit Board Pcb 3

Double Side 3oz Immersion Gold Automotive Circuit Board Pcb 4Double Side 3oz Immersion Gold Automotive Circuit Board Pcb 5



Testing service


Haina lean Electronics provides custom test service according to client's requirements and products.
Usually Haina lean Electronics Co.,Ltd PCBA Tech offers a full range of testing service. Including:
1. AOI(Automatic Optical Inspection)
2. Function Testing
3. In Circuit Testing
4. Testing Jig
5. Testing Service
6. X-Ray for BGA Testing
7. Printing Solder Paste Test
Each board is carefully examined by our dedicated inspection team using AOI and high magnification viewers.
Using our X-Ray machine, we test PCBs to component level and all wiring is fully inspected and tested.
Flash testing and earth bonding tests can also be undertaken where required.



Partners


Double Side 3oz Immersion Gold Automotive Circuit Board Pcb 6


Common packaging


PCB: Vacuum packaging with carton box
PCBA: ESD packaging with carton box


Double Side 3oz Immersion Gold Automotive Circuit Board Pcb 7


Why choose us?



Welcome to visit our factory, Haina lean Electronics Co., Ltd.
1. Experienced: Focus on PCB And PCBA munufacturing over 10 years.
2. Professional: Expertise engineer with barrier-free English
3. Rapid delivery: On-time delivery rate reaches 98%
4.Cost effective: No excessive profits. Lower cost with same quality And service



FAQ

Q1.

What's your MOQ ?
No Moq ,We accept small orders as well as mass production.



Q2.

For small quantity orders, can you produce prototype PCB?

Haina lean Electronics Co., has the capability to produce circuit boards in any amount.

Q3.

Can You provide fast rotating PCB ?
Yes , we can provide fast service 24 hours .

Q4.

What are the services you can provide ?
One-stop contract manufacturing
PCB board, PCB Design & Layout, PCB Assembly, PCBA programming & functional testing, Electronic components purchasing service,              Enclosure molding & final assembly with labels,instructions,enclosure, boxes.


Q5.

Whether all PCBA s will be tested before delivery ?
Yes , we will test each piece of PCBA product under your testing methods ,to ensure quality and functionality .

Q6.

Do you provide OEM service ?
Yes ,we offer PCB and PCBA OEM Service , we manufacture the PCB and PCBA products to your design and requirements .



Q7.

Shipping Cost ?
The shipping cost is determined by the destination ,weight ,packing size of the goods .We can provide shipping, air, land, express and other          transportation services .



Q8.

Do you accept process materials supplied by clients?
Yes, we can provide component source, and we also accept component from client. OEM and ODM orders are accepted.


Double Side 3oz Immersion Gold Automotive Circuit Board Pcb 8
