Turnkey PCB assembly means that the supplier handles all aspects of PCB solutions, including components procuring and PCB manufacturing, picking and placing components on specific locations on your custom PCBs. In essence, full turnkey PCB assembly gives the buyer greater freedom to focus on PCB design, while the supplier takes care of the rest, which is why it is a leading form of one-stop electronic assembly .
FACTORY CAPABILITIES | |||
No. | Items | 2019 | 2020 |
1 | HDI Capabilities | HDI ELIC (4+2+4) | HDI ELIC(5+2+5) |
2 | Max layer count | 32L | 36L |
3 | Board Thickness | Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm | Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm |
4 | Min.Hole Size |
Laser 0.075mm Mechnical 0.15 |
Laser 0.05mm Mechnical 0.15 |
5 | Min Line Width/Space | 0.035mm/0.035 | 0.030mm/0.030mm |
6 | Copper Thickness | 1/3oz-4oz | 1/3oz-6oz |
7 | Size Max Panel size | 700x610mm | 700x610mm |
8 | Registration Accuracy | +/-0.05mm | +/-0.05mm |
9 | Routing Accuracy | +/-0.075mm | +/-0.05mm |
10 | Min.BGA PAD | 0.15mm | 0.125mm |
11 | Max Aspect Ratio | 10:1 | 10:1 |
12 | Bow and Twist | 0.50% | 0.50% |
13 | Impedance Control Tolerance | +/-8% | +/-5% |
14 | Daily output | 3,000m2 (Max capacity of equipment) | 4,000m2 (Max capacity of equipment) |
15 | Surface Finishing | HASL Lead Free /ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD | |
16 | Raw Material | FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI |
PCBA Capability | |||
Material Type | Item | Min | Max |
PCB | Dimension (length,width,height.mm) | 50*40*0.38 | 600*400*4.2 |
Material | FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC | ||
Surface finish | HASL,OSP,Immersion gold,Flash Gold Finger | ||
Components | Chip&IC | 1005 | 55mm |
BGA Pitch | 0.3mm | - | |
QFP Pitch | 0.3mm | - |
Service value
Independent quotation system to quickly serve the market
PCB manufacturing
High-tech PCB and PCB assembly production line
Material purchasing
A team of experienced electronic component procurement engineers
SMT post soldering
Dust-free workshop, high-end SMT patch processing
Printed circuit boards And PCB Assembly are mainly used for many communication industry, medical equipments, consumer electronics , automobile industry ,automotive electronics , audio and video, optoelectronics, robotics, hydroelectric power, aerospace, education, power supply, printer etc industries.
1.What are needed for quotation?
PCB: Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ......)
PCBA: PCB information, BOM, (Testing documents...)
2. What file formats do you accept for production?
Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)
3.Are my files safe?
Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third party.
4.MOQ?
There is no MOQ .We can flexibly handle small and mass production.
5.Shipping Cost ?
The shipping cost is determined by the destination ,weight ,packing size of the goods .We can provide shipping, air, land, express and other transportation services .
6.How to ensure high-quality production?
The process is strictly controlled under ISO 9001:2015 standards.
Most of our advanced equipment and tools are imported from abroad. Such as Flying Probe, X-ray Inspection, AOI (Automated Optical Inspector) and ICT (in-circuit testing).
We have a very professional QC team.
Q7.What are the services you can provide ?
One-stop contract manufacturing
A:PCB Assembly;
B:PCB Design & Layout
C:PCBA programming & functional testing;
D:Electronic components purchasing service;
E:Enclosure molding & final assembly with labels,instructions,enclosure, boxes.
Q8.Whether all PCBA s will be tested before delivery ?
Yes , we will test each piece of PCBA product under your testing methods ,to ensure quality and functionality .
Q9.Do you provide OEM service ?
Yes ,we offer PCB and PCBA OEM Service , we manufacture the PCB and PCBA products to your design and requirements .
