The rigid-flex board is the flexible circuit board and the rigid circuit board, referred to as FPCB. After pressing and other processes, they are combined according to the relevant process requirements to form a circuit board with FPC characteristics and PCB characteristics.
It can be used in some products with special requirements. It has both a certain flexible area and a certain rigid area. It is of great help to save the internal space of the product, reduce the volume of the finished product, and improve the performance of the product.
Our services include: circuit board design and layout, 2-46 layers PCB manufacturing, professional FPC production, FPCB Production .electronic components purchasing, SMT professional processing, Soldering and Assembly, especially sample and small bulk orders. we have the advantages of a quick quote, fast production, fast delivery.
|Quality Grade||Standard IPC 2||Material||FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI|
|Number of Layers||1 - 8layers||Board Size||Custom|
|Order Quantity||1pc - 10000+pcs||Board Thickness||0.1mm - 0.8mm|
|Build Time||2days - 5weeks||Copper Weight (Finished)||0.5oz - 6.0oz|
|Min Tracing/Spacing||3mil/3mil||Silkscreen Sides||As per the file|
|Solder Mask Sides||As per the file||Silkscreen Color||White, Black, Yellow|
|Solder Mask Color||Green, White, Blue, Black, Red, Yellow||Surface Finish||HASL - Hot air solder leveling|
|Solder-stop coating---Soldermask oil||Green, White, Blue, Black, Red, Yellow||Lead - free HASL - RoHS|
|Solder-stop coating---Coverlay||PI and PET film||ENIG - RoHS|
|Min Annular Ring||3mil||Immersion Tin - RoHS|
|Min Drilling Hole Diameter||8mil||OSP - RoHS|
|Min. hole size---Drilling (PTH)||0.2mil||Other Techniques||Peelable solder mask ;Gold fingers ;Stiffener (only for PI/FR4 substrate)|
