High Light
Copper SMT printed circuit board assembly
,1.6mm SMT printed circuit board assembly
,0.3oz surface mount PCB assembly
-
Product NameSMT Surface Mount Circuit Board Assemblies
-
Copper Thickness0.3oz - 6oz
-
Max Board Size700x610mm Custom
-
Min. Line Spacing0.030mm / 0.030mm
-
Board Thickness0.3-3.5mm
-
Min. Hole SizeLaser 0.05mm ; Mechnical 0.15
-
Solder Mask ColorBlue.green.red.black.white.etc
-
CertificationRoHS, ISO9001, UL, SGS
-
Surface FinishingHASL,OSP,ENIG,HASL Lead Free,Immersion Gold
-
MaterialFR4 /Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI
-
ApplicationCommunication Equipment, Industrial Control, Consumer Electronics, Medical Equipment, Aerospace, Light-emitting Diode Lighting, Automotive Electronics
-
ServiceOne-stop Service,PCB&PCBA,ODM And OEM
-
Place of OriginCHINA
-
Brand NameHNL-PCBA
-
CertificationISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000
-
Model NumberPCBA-01
-
Minimum Order Quantity1 PC
-
PriceNegotiable
-
Packaging DetailsESD packaging with carton box
-
Delivery Time1-7days
-
Payment TermsT/T, Western Union, L/C, MoneyGram
-
Supply Ability10,000,000 Point /Day
1.6mm Copper SMT Printed Circuit Board Assembly
Quick Turn PCBA 1.6mm copper board SMT Surface Mount Circuit Board Assemblies
SMT Surface Mount Circuit Board Assemblies Introduction
PCB Assembly Types: Surface mount, Thro-hole, Mixed technology (SMT & Thru-hole), Single or double sided placement, Conformal coating, Shield cover assembly for EMI emission control .
Printed circuit board (PCB) assemblies include surface-mount technology (SMT) PCB prototypes, PCBA prototype assembly, PCB sample assembly, etc. The term prototype PCB Assembly refers to a fast prototype PCBA used to test the function of new electronic designs.
The prototype PCB assembly section of our manufacturing facility has a unique layout that allows for flexible use of both automated and manual parts-loading stations. Our engineers is qualified and experienced in producing surface-mount (SMT), through-hole (THT) and mixed-technology components and fine-pitch parts and ball grid arrays (BGAs) for high-density FR-4 PCBs .
PCB CAPABILITIES
| Layers | 1 - 36 L |
| Substrate | FR-4,CTI600,Tg150 ,Tg170,Anti CAF,Halogen-free,,High frequency,Tg170&HF |
| Max. panel size | 700x610mm |
| Board thickness | 0.3 mm - 3.5 mm. |
| Copper thickness | 1/3 oz. to 6 oz. (outer) (Max) |
| Hole | > 0.15mm. |
| Aspect Ratio | 10 : 1 |
| Min. track width | 3.0 mils(partial) |
| Min. track space | 3.0mils(partial) |
| Min. S/M bridge | 3mil |
| Hole plugging diameter | 0.3 mm~0.55 mm. |
| Impedance tolerance | +/- 10%. |
| Color of S/M | Green,white,black,red,orange,yellow,blue,purple |
| Surface treatment | OSP,HAL,HAL LF,ENIG,Hard gold,Imm Ag,Imm Sn,Peelable soldermask,Carbon ink print,Selective hard gold |
PCBA CAPABILITIES
| PCBA Capability | |||
| Material Type | Item | Min | Max |
| PCB | Dimension (length,width,height.mm) | 50*40*0.38 | 600*400*4.2 |
| Material | FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC | ||
| Surface finish | HASL,OSP,Immersion gold,Flash Gold Finger | ||
| Components | Chip&IC | 1005 | 55mm |
| BGA Pitch | 0.3mm | - | |
| QFP Pitch | 0.3mm | - | |
Our advantage
|
Service value Independent quotation system to quickly serve the market |
Material purchasing A team of experienced electronic component procurement engineers |
|
PCB manufacturing High-tech PCB and PCB assembly production line |
SMT post soldering Dust-free workshop, high-end SMT patch processing |
Why choose us?
Welcome to visit our factory, Haina lean Electronics Co., Ltd.
1. Experienced: Focus on PCB And PCBA munufacturing over 10 years.
2. Professional: Expertise engineer with barrier-free English
3. Rapid delivery: On-time delivery rate reaches 98%
4.Cost effective: No excessive profits. Lower cost with same quality And service
Delivery Time
| Product Type | Qty | Normal lead time | Quick-turn lead time |
| SMT+DIP | 1-50 | 1WD-2WD | 8H |
| SMT+DIP | 51-200 | 2WD-3WD | 1.5WD |
| SMT+DIP | 201-2000 | 3WD-4WD | 2WD |
| SMT+DIP | ≥2001 | 4WD-5WD | 3WD |
| PCBA(2-4Layer) | 1-50 | 2.5WD-3.5WD | 1WD |
| PCBA(2-4Layer) | 51-2000 | 5WD-6WD | 2.5WD |
| PCBA(2-4Layer) | ≥2001 | ≥7WD | 5WD |
| PCBA(6-10Layer) | 1-50 | 3WD-4WD | 2.5WD |
| PCBA(6-10Layer) | 51-2000 | 7WD-8WD | 6WD |
| PCBA(10-HDILayer) | 1-50 | 7WD-9WD | 5WD |
| PCBA(10-HDILayer) | 51-2000 | 9WD-11WD | 7WD |
SMT Surface Mount Circuit Board Assemblies Application Field
PCB Assembly are widely used in the following areas:
1. communication equipment,
2. industrial control,
3.consumer electronics,
4.medical equipment,
5. aerospace,
6.light-emitting diode lighting,
7.automotive electronics etc
Workshop
Partners
Common packaging
PCB: Vacuum packaging with carton box
PCBA: ESD packaging with carton box
FAQ
Q1.What are needed for quotation?
PCB: Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ......)
PCBA: PCB information, BOM, (Testing documents...)
Q2. What file formats do you accept for production?
Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)
Q3.Are my files safe?
Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third party.
Q4.MOQ?
There is no MOQ .We can flexibly handle small and mass production.
Q5.Shipping Cost ?
The shipping cost is determined by the destination ,weight ,packing size of the goods .We can provide shipping, air, land, express and other transportation services .
Q6.How to ensure high-quality production?
The process is strictly controlled under ISO 9001:2015 standards.
Most of our advanced equipment and tools are imported from abroad. Such as Flying Probe, X-ray Inspection, AOI (Automated Optical Inspector) and ICT (in-circuit testing).
We have a very professional QC team.
Q7.What are the services you can provide ?
One-stop contract manufacturing
A:PCB Assembly;
B:PCB Design & Layout
C:PCBA programming & functional testing;
D:Electronic components purchasing service;
E:Enclosure molding & final assembly with labels,instructions,enclosure, boxes.
Q8.Whether all PCBA s will be tested before delivery ?
Yes , we will test each piece of PCBA product under your testing methods ,to ensure quality and functionality .
Q9.Do you provide OEM service ?
Yes ,we offer PCB and PCBA OEM/ODM Service , produce the PCB and PCBA products as your design and requirements .
Our services cover all industries and reach all parts of the world.
