Hasl Multi Layer 0.6oz 1.6mm Medical Pcb Assembly

Hasl Multi Layer 0.6oz 1.6mm Medical Pcb Assembly

  • High Light

    1.6mm medical pcb assembly

    ,

    0.6oz medical pcb assembly

    ,

    hasl medical pcb assembly

  • Product Name
    Medical PCB Assembly
  • Material
    Fr4 High Tg
  • Copper Thickness
    0.3OZ To 6OZ
  • Min. Line Width/spacing
    0.030mm
  • Board Thickness
    0.5mm, 1.6mm,...... 3.5mm
  • Min. Hole Size
    Laser 0.05mm ; Mechnical 0.15
  • Surface Finishing
    HASL Lead Free
  • Solder Mask Color
    Green. Red. Blue. White. Black.Yellow Etc.
  • PCB Assembly Process
    Mixed; SMT, DIP, THT
  • Pcb Test
    Flying Probe And AOI (Default)/Fixture Test,Flying-Probe PCB Test
  • Place of Origin
    CHINA
  • Brand Name
    HNL-PCBA
  • Certification
    ISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000
  • Model Number
    PCB Assembly 04
  • Minimum Order Quantity
    1 PC
  • Price
    Negotiable
  • Packaging Details
    ESD packaging with carton box
  • Delivery Time
    1-10days
  • Payment Terms
    T/T, Western Union, L/C, MoneyGram
  • Supply Ability
    10,000,000 Point /Day

Hasl Multi Layer 0.6oz 1.6mm Medical Pcb Assembly

HASL Multi-Layer 0.6oz 1.6mm Electronic Circuit Medical PCB Assembly



Medical PCB Assembly brief Introduction



We know that the development of medical PCB applications is as fast as the medical device industry itself.

After you visit our one-stop EMS shop. We provide our customers with PCB Manufacturing, PCB Assembly and Components Sourcing service to save your time & cost.

We offer competitive pricing, as well as flexible shipment plans to you. Our engineers is qualified and experienced in producing surface-mount (SMT), through-hole (THT) and mixed-technology components and fine-pitch parts and ball grid arrays (BGAs) for high-density FR-4 PCBs .



PCB CAPABILITIES





Layers 1 - 46 L (Custom )
Substrate FR-4,CTI600,Tg180,,Anti CAF,Halogen-free,,High frequency,Tg170&HF
Max. panel size 700x610mm (Custom)
Board thickness 0.3 mm - 3.5 mm.
Copper thickness 1/3 oz. to 6 oz. (outer) (Max)
Hole > 0.15mm.
Aspect Ratio 10 : 1
Min. track width 3.0 mils(partial)
Min. track space 3.0mils(partial)
Min. S/M bridge 3mil
Hole plugging diameter 0.3 mm~0.55 mm.
Impedance tolerance +/- 10%.
Color of S/M green,white,black,red,orange,yellow,blue,purple
Surface treatment OSP,HAL,HAL LF,ENIG,Hard gold,Imm Ag,Imm Sn,Peelable soldermask,Carbon ink print,Selective hard gold


PCBA CAPABILITIES



PCBA Capability
Material Type Item Min Max
PCB Dimension (length,width,height.mm) 50*40*0.38 600*400*4.2
Material FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC
Surface finish HASL,OSP,Immersion gold,Flash Gold Finger
Components Chip&IC 1005 55mm
BGA Pitch 0.3mm -
QFP Pitch 0.3mm -



Our SMT capabilities:



SMT Assembly: SMT provides a flexible high technology. These solutions include:

7 high-speed placement machines,

7 automatic printers with fiducial alignment,

2 X-ray machines,

BGA maintenance machines,

ICT test machines



Our DIP function:



A-8 semi-assembly production line with four wave soldering machines

1 U-shaped automatic assembly line for box-type building products with test stations

High temperature / low temperature aging test furnace B-4 for products required for aging test

With time control and temperature control

All products are 100% inspected and tested during the DIP process

Haina lean Electronics Co.,Ltd is a competitive China customize pcba for medical breathing machine OEM manufacturer, supplier and vendor, you can get quick turn customize pcba for medical breathing machine production prototypes and samples from our factory.

Hot Tags: customize pcba for medical breathing machine, China, supplier, manufacturer, factory, OEM manufacturer, vendor, samples, production, prototypes, quick turn



Medical PCB Assembly PCB SMT Assembly Process



1.Solder Paste stenciling---2.Surface Mount Technology (Pick and Place)---3.Reflow Soldering---4.Inspection and Quality Control---5.Through-Hole Component Insertion (DIP Process)---6.Final Inspection and Functional Test
