High Light
fr4 double sided pcba
,osp double sided pcba
,osp rapid pcba
-
Product NamePCBA Rapid
-
LayersCustomized
-
Copper Thickness1oz 2oz 3oz ...6oz
-
Min. Line Spacing / Width0.030mm / 0.030mm
-
Board Thickness1.0mm 1.2mm 1.6mm...3.5mm
-
Min. Hole SizeLaser 0.05mm ; Mechnical 0.15
-
Solder Mask ColorGreen,white,black,red,orange,yellow,blue,purple
-
Surface TreatmentOSP,HAL,HAL LF,ENIG,Hard Gold,Imm Ag,Imm Sn,Peelable Soldermask,Carbon Ink Print,Selective Hard Gold
-
Base MaterialHigh Tg FR-4, Halogen Free FR-4, Thick Copper FR-4, Aluminium Based, Rogers, Taconic
-
ApplicationIndustry/Medical/Consumer Electronic /Smart Home /elevator Etc.
-
Place of OriginCHINA
-
Brand NameHNL-PCBA
-
CertificationISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000
-
Model NumberRapid PCBA
-
Minimum Order Quantity1 PC
-
PriceNegotiable
-
Packaging DetailsESD packaging with carton box
-
Delivery Time1-7days
-
Payment TermsT/T, Western Union, L/C, MoneyGram
-
Supply Ability10,000,000 Point /Day
Electronics Prototype Fr4 Double Sided Pcba Rapid Custom OSP
Electronics Prototype Custom Fr4 Pcb Manufacturer Double Sided PCBA Rapid
Rapid PCBA Introduction
Our company can provide fast PCBA service. Including complete turnkey and partial turnkey. For a full turnkey, we are responsible for the entire process, including the preparation of printed circuit boards, electronic component procurement, online order tracking, continuous monitoring of quality and final assembly. For part of the turnkey, customers can provide PCB and some components, and the rest will be handled by us.
Factory Capacity
| No. | Items | |
| 1 | HDI Capabilities | HDI ELIC(5+2+5) |
| 2 | Max layer count | 36L |
| 3 | Board Thickness | Core thickness 0.05mm-1.5mm ,Fineshed board thickness0.3-3.5mm |
| 4 | Min.Hole Size |
Laser 0.05mm Mechnical 0.15 |
| 5 | Min Line Width/Space | 0.030mm/0.030mm |
| 6 | Copper Thickness | 1/3oz-6oz |
| 7 | Size Max Panel size | 700x610mm |
| 8 | Registration Accuracy | +/-0.05mm |
| 9 | Routing Accuracy | +/-0.05mm |
| 10 | Min.BGA PAD | 0.125mm |
| 11 | Max Aspect Ratio | 10:1 |
| 12 | Bow and Twist | 0.50% |
| 13 | Impedance Control Tolerance | +/-5% |
| 14 | Daily output | 4,000m2 (Max capacity of equipment) |
| 15 | Surface Finishing | ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD |
| 16 | Raw Material | FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI |
PCBA CAPABILITIES
| PCBA Capability | ||||||
| Material type | PCB | Components | ||||
| Item | Dimension (Length, width,height. mm) | Material | Surface finish | Chip&IC | BGA Pitch | QFP Pitch |
| Min | 50*40*0.38 | FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC | HASL, OSP, Immersion gold, Flash Gold Finger | 1005 | 0.3mm | 0.3mm |
| Max | 600*400*4.2 | |||||
Our service
1.PCB Design & Layout 2.PCB Prototyping
3.PCB Fabrication 4.Turnkey Prototype PCB Assembly
5.PCB Assembly Service 6.Contract PCB Assembly
7.Trunkey PCB Assembly 8.Components sourcing
9.Function test 10.conformal coating
11.complete assembly
Workshop & Equipment
AL-SPI-IA
solder paste printing equipment
wave-soldering
automatic printing equipment
60times magnifying glass
material baking equipment
X-ray welding inspection
Semi-automatic printing equipment
component counting equipment
Online AOI detector
Reflow welding equipment
Mydata welding equipment
PCBA Application
Printed circuit boards And PCB Assembly are mainly used for many communication industry, medical equipments, consumer electronics ,automotive electronics , Elevator,audio and video, optoelectronics, robotics, hydroelectric power, Elevator,aerospace, education, power supply, printer ,Auto Industry ,Smart Home.etc.
