4-6 Layers 1.6 Mm 1 Oz Complete Turnkey Pcb Assembly

4-6 Layers 1.6 Mm 1 Oz Complete Turnkey Pcb Assembly

  • High Light

    complete turnkey pcb assembly

    ,

    1 oz multilayer pcb assembly

    ,

    cem1 turnkey pcb assembly

  • Product Name
    Complete Assembled PCB
  • Material
    FR4 CEM1 CEM3 Hight TG
  • Copper Thickness
    1OZ 2OZ 3OZ 4OZ 5OZ...
  • Min. Line Spacing
    0.030mm
  • Board Thickness
    0.3mm, 1mm, 2mm .......3.5mm
  • Min. Line Width
    0.03mm
  • Min. Hole Size
    Laser 0.05mm ; Mechnical 0.15
  • Surface Finishing
    HASL,OSP,ENIG,HASL Lead Free
  • Pcb Assembly Method
    Mixed,BGA,SMT,Through-hole
  • Solder Mask Color
    Blue.green.red.black.white.etc
  • Place of Origin
    CHINA
  • Brand Name
    HNL-PCBA
  • Certification
    ISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000
  • Model Number
    PCB Assembly
  • Minimum Order Quantity
    1 PC
  • Price
    Negotiable
  • Packaging Details
    ESD packaging with carton box
  • Delivery Time
    1-7days
  • Payment Terms
    T/T, Western Union, L/C, MoneyGram
  • Supply Ability
    10,000,000 Point /Day

4-6 Layers 1.6 Mm 1 Oz Complete Turnkey Pcb Assembly

PCB Prototype And Assembly 4-6 Layers 1.6mm 1OZ Complete Assembled PCB



PCB Assembly Introduction

Turnkey PCB assembly means that the supplier handles all aspects of PCB solutions, including components procuring and PCB manufacturing, picking and placing components on specific locations on your custom PCBs. In essence, full turnkey PCB assembly gives the buyer greater freedom to focus on PCB design, while the supplier takes care of the rest, which is why it is a leading form of one-stop electronic assembly.



For Turnkey PCB Assembly, all you need to do is to send us your PCB assembly Bill of Materials (BOM) list. ( a document or a spreadsheet format containing the PCB specification selection ), the number of layers, quantity, and all dimensions necessary. In addition, you also need to include a CAD-generated Gerber or Centroid file for the top/bottom copper, Silkscreen and other details.
Next, we will send a formal quote for your order approval before production . you can fix it if there’s any problem .



PCB CAPABILITIES



FACTORY CAPABILITIES
No. Items 2019 2020
1 HDI Capabilities HDI ELIC (4+2+4) HDI ELIC(5+2+5)
2 Max layer count 32L 36L
3 Board Thickness Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm Core thickness 0.05mm-1.5mm ,Fineshed board thickness 0.3-3.5mm
4 Min.Hole Size

Laser 0.075mm

Mechnical 0.15

Laser 0.05mm

Mechnical 0.15

5 Min Line Width/Space 0.035mm/0.035 0.030mm/0.030mm
6 Copper Thickness 1/3oz-4oz 1/3oz-6oz
7 Size Max Panel size 700x610mm 700x610mm
8 Registration Accuracy +/-0.05mm +/-0.05mm
9 Routing Accuracy +/-0.075mm +/-0.05mm
10 Min.BGA PAD 0.15mm 0.125mm
11 Max Aspect Ratio 10:1 10:1
12 Bow and Twist 0.50% 0.50%
13 Impedance Control Tolerance +/-8% +/-5%
14 Daily output 3,000m2 (Max capacity of equipment) 4,000m2 (Max capacity of equipment)
15 Surface Finishing HASL Lead Free /ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD
16 Raw Material FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI



PCBA CAPABILITIES



PCBA Capability
Material Type Item Min Max
PCB Dimension (length,width,height.mm) 50*40*0.38 600*400*4.2
Material FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC
Surface finish HASL,OSP,Immersion gold,Flash Gold Finger
Components Chip&IC 1005 55mm
BGA Pitch 0.3mm -
QFP Pitch 0.3mm -



4-6 Layers 1.6 Mm 1 Oz Complete Turnkey Pcb Assembly 0

4-6 Layers 1.6 Mm 1 Oz Complete Turnkey Pcb Assembly 1



Turnkey PCB Assembly Application Field



Printed circuit boards And PCB Assembly are mainly used for many communication industry, medical equipments, consumer electronics and automobile industry ,automotive electronics , audio and video, optoelectronics, robotics, hydroelectric power, aerospace, education, power supply, printer etc industries.





4-6 Layers 1.6 Mm 1 Oz Complete Turnkey Pcb Assembly 2



Our Workshop

4-6 Layers 1.6 Mm 1 Oz Complete Turnkey Pcb Assembly 3

4-6 Layers 1.6 Mm 1 Oz Complete Turnkey Pcb Assembly 4

4-6 Layers 1.6 Mm 1 Oz Complete Turnkey Pcb Assembly 5



FAQ



1.What are needed for quotation?
PCB: Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ......)
PCBA: PCB information, BOM, (Testing documents...)

2. What file formats do you accept for production?
Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)

3.Are my files safe?
Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third party.

4.MOQ?
There is no MOQ .We can flexibly handle small and mass production.

5.Shipping Cost ?

The shipping cost is determined by the destination ,weight ,packing size of the goods .We can provide shipping, air, land, express and other transportation services .

6.How to ensure high-quality production?
The process is strictly controlled under ISO 9001:2015 standards.
Most of our advanced equipment and tools are imported from abroad. Such as Flying Probe, X-ray Inspection, AOI (Automated Optical Inspector) and ICT (in-circuit testing).
We have a very professional QC team.

Q7.What are the services you can provide ?

One-stop contract manufacturing
A:PCB Assembly;
B:PCB Design & Layout
C:PCBA programming & functional testing;
D:Electronic components purchasing service;
E:Enclosure molding & final assembly with labels,instructions,enclosure, boxes.

Q8.Whether all PCBA s will be tested before delivery ?

Yes , we will test each piece of PCBA product under your testing methods ,to ensure quality and functionality .

Q9.Do you provide OEM service ?

Yes ,we offer PCB and PCBA OEM Service , we manufacture the PCB and PCBA products to your design and requirements .
