Double sided PCBs have two sided traces with a top and bottom layer. Assembler mount conductive copper and components on both sides of the circuit board, which allows the traces to cross over each other. This results in a higher density of circuits without the need of point-to-point soldering. For these types of circuit boards are more complex than single sided PCBs, it would be more difficult to produce.
However, the benefits of using double sided PCBs far outweigh the cons.
Quality Grade | Standard IPC 2 | Material | FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI |
Number of Layers | 1 - 8layers | Board Size | Custom |
Order Quantity | 1pc - 10000+pcs | Board Thickness | 0.1mm - 0.8mm |
Build Time | 2days - 5weeks | Copper Weight (Finished) | 0.5oz - 6.0oz |
Min Tracing/Spacing | 3mil/3mil | Silkscreen Sides | As per the file |
Solder Mask Sides | As per the file | Silkscreen Color | White, Black, Yellow |
Solder Mask Color | Green, White, Blue, Black, Red, Yellow | Surface Finish | HASL - Hot air solder leveling |
Solder-stop coating---Soldermask oil | Green, White, Blue, Black, Red, Yellow | Lead - free HASL - RoHS | |
Solder-stop coating---Coverlay | PI and PET film | ENIG - RoHS | |
Min Annular Ring | 3mil | Immersion Tin - RoHS | |
Min Drilling Hole Diameter | 8mil | OSP - RoHS | |
Min. hole size---Drilling (PTH) | 0.2mil | Other Techniques | Peelable solder mask ;Gold fingers ;Stiffener (only for PI/FR4 substrate) |
Our DIP function:
A-8 semi-assembly production line with four wave soldering machines
1 U-shaped automatic assembly line for box-type building products with test stations
High temperature / low temperature aging test furnace B-4 for products required for aging test
With time control and temperature control
All products are 100% inspected and tested during the DIP process
Haina lean Electronics Co.,Ltd is a competitive China customize pcba for medical breathing machine OEM manufacturer, supplier and vendor, you can get quick turn customize pcba for medical breathing machine production prototypes and samples from our factory.
Hot Tags: customize pcba for medical breathing machine, China, supplier, manufacturer, factory, OEM manufacturer, vendor, samples, production, prototypes, quick turn
Double Side PCB Assembly Process
1.Solder Paste stenciling---2.Surface Mount Technology (Pick and Place)---3.Reflow Soldering---4.Inspection and Quality Control---5.Through-Hole Component Insertion (DIP Process)---6.Final Inspection and Functional Test
