OEM Tg170 HASL HF 14 layers Prototype High Frequency PCB



High Frequency PCB Introduction



And developing new products always use high frequency substrate, satellite system, mobile telephone receiving base station and so on, these communication products must use high frequency PCB.

Haina lean Electronics Co., Ltd produce HDI board, Fast PCB board, RF PCB board, PCBA, high frequencyPCB board ,high speed board and rigid-flex board, etc., to meet customers' various demands. We have handled hundreds of thousands of PCB projects, and covered almost all kinds of substrate materials including FR4, Aluminum, Rogers, etc.



Basic Data/Information



The high frequency of electronic equipment is the development trend, especially in the development of wireless networks, satellite communications. Information products are moving towards high-speed and high-frequency , Communication products such as satellite systems and mobile phone receiving base stations must use high-frequency circuit boards.



The features of high frequency PCB as following:

1. DK should be small and stable enough, usually the smaller the better, high DK may lead to signal transmission delay.

2. DF should be small, which mainly affect quality of signal transmission, the smaller DF could make smaller signal wastage accordingly.

3. The thermal expansivity should be the same with copper foil as much as possible, because the difference will lead to copper foil separated in the changes of cold and heat.

4. Water absorptivity must be low, high water absorptivity will affect DK and DF when in the wet environment.

5. Heat resisting property, chemistry resisting, impact endurance, peel off resisting must be good.

Generally speaking, high frequency can be defined as frequency above 1GHz. Currently, polyfluortetraethylene(PTFE) material is widely used in high frequency PCB manufacturing, it's also called Teflon, which frequency is normally above 5GHz. In addition, FR4 or PPO substrate can be used to the product frequency among 1GHz~10GHz.
