ROHS OEM Multilayer Electronics Automotive PCBA 1OZ

ROHS OEM Multilayer Electronics Automotive PCBA 1OZ

  • High Light

    OEM Automotive PCBA 1OZ

    ,

    Automotive PCBA 1OZ

    ,

    ROHS OEM PCBA 1OZ

  • Product Name
    Automotive PCBA
  • Material
    FR4, HASL, Aluminum, CEM-1, High TG
  • Copper Thickness
    1/3OZ, 1OZ, 2OZ, 3OZ, 4OZ, 5OZ, 6OZ
  • Min. Line Spacing
    0.030mm
  • Board Thickness
    Core Thickness 0.05mm-1.5mm ,Fineshed Board Thickness 0.3-3.5mm
  • Min. Hole Size
    ≥0.05
  • Surface Finishing
    HASL, Lead Free HASL, HASL/OSP/ENIG
  • Legond Color
    White
  • Layers
    1~48;as Requires
  • Application
    Electronics Device,LED Products,rigid Fpc,LED Controller
  • Service
    One-stop Service,24 Hours At Your Service,competitive Price,OEM Services Provided,professional Engineer
  • Solder Mask Color
    Blue.green.red.black.white.etc
  • Place of Origin
    CHINA
  • Brand Name
    HNL-PCBA
  • Certification
    ISO9001,IS16949, ISO14001,ROHS ,UL, IPC-A ,QC080000
  • Model Number
    PCB Assembly 06
  • Minimum Order Quantity
    1 PC
  • Price
    Negotiable
  • Packaging Details
    ESD packaging with carton box
  • Delivery Time
    1-7days
  • Payment Terms
    T/T, Western Union, L/C, MoneyGram
  • Supply Ability
    10,000,000 Point /Day

ROHS OEM Multilayer Electronics Automotive PCBA 1OZ

ROHS OEM Multilayer Automotive Electronics PCB assembly Automotive PCBA



Automotive PCBA Introduction



PCBA is the abbreviation of Printed Circuit Board Assembly in English, that is to say, PCB blank board goes through SMT loading, or the entire process of DIP plug-in, referred to as PCBA, and the standard way of writing in Europe and America is PCB'A.

Haina lean Electronics Co.,Ltdis a competitive China automotive driver circuit board prototype OEM manufacturer, supplier and vendor, you can get quick turn automotive driver circuit board prototype production prototypes and samples from our factory.



PCBA CAPABILITIES



Base material FR4,High-TG FR4,CEM3,aluminum, High frequency(Rogers,Taconic,Aron,PTFE,)
Layers 1-46
Copper Thickness 0.3oz,0.5oz, 1oz, 2oz, 3oz,4oz,5oz, 6oz
Dielectric Thickness 0.05mm, 0.075mm, 0.1mm,0.15mm,0.2mm
board Core Thickness 0.4mm,0.6mm, 0.8mm, 1.0mm, 1.2mm,
1.5mm, 2.0mm, 3.0mm and 3.2mm
Board Thickness 0.3mm - 4.0mm
Thickness Tolerance +/-10%
Surface Finishing HASL lead free,ENIG,Plated Gold,Immersion Gold,OSP
Solder Mask Color Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue
Legend Color Black, White etc
Assembly Types Surface mount
Thro-hole
Mixed technology (SMT & Thru-hole)
Single or double sided placement
Conformal coating
Shield cover assembly for EMI emission control
Parts Procurement Full Turnkey, Partial Turnkey, Kitted / Consigned
Component types SMT 01005 or larger
BGA 0.4mm pitch, POP (Package on Package)
WLCSP 0.35mm pitch
Hard metric connectors
Cable & wire
Other Techniques Free DFM Review
Box Build Assembly
100% AOI test and X-ray test for BGA
Components cost-down
Function test as custom
Protection technology



Automotive PCBA process



ROHS OEM Multilayer Electronics Automotive PCBA 1OZ 0

ROHS OEM Multilayer Electronics Automotive PCBA 1OZ 1



Our SMT capabilities:



SMT Assembly: SMT provides a flexible high technology.

These solutions include: 7 high-speed placement machines, 7 automatic printers with fiducial alignment, 2 X-ray machines, BGA maintenance machines, ICT test machines



Our DIP function:



A-8 semi-assembly production line with four wave soldering machines

1 U-shaped automatic assembly line for box-type building products with test stations

High temperature / low temperature aging test furnace B-4 for products required for aging test

With time control and temperature control

All products are 100% inspected and tested during the DIP process

Haina lean Electronics Co.,Ltd is a competitive China customize pcba for medical breathing machine OEM manufacturer, supplier and vendor, you can get quick turn customize pcba for medical breathing machine production prototypes and samples from our factory.

Hot Tags: customize pcba for medical breathing machine, China, supplier, manufacturer, factory, OEM manufacturer, vendor, samples, production, prototypes, quick turn.

Lead-Free PCB Assembly Delivery Time



Product Type Qty Normal lead time Quick-turn lead time
SMT+DIP 1-50 1WD-2WD 8H
SMT+DIP 51-200 2WD-3WD 1.5WD
SMT+DIP 201-2000 3WD-4WD 2WD
SMT+DIP ≥2001 4WD-5WD 3WD
PCBA(2-4Layer) 1-50 2.5WD-3.5WD 1WD
PCBA(2-4Layer) 51-2000 5WD-6WD 2.5WD
PCBA(2-4Layer) ≥2001 ≥7WD 5WD
PCBA(6-10Layer) 1-50 3WD-4WD 2.5WD
PCBA(6-10Layer) 51-2000 7WD-8WD 6WD
PCBA(10-HDILayer) 1-50 7WD-9WD 5WD
PCBA(10-HDILayer) 51-2000 9WD-11WD 7WD



Automotive PCBA Application Field



Printed circuit boards And PCB Assembly are mainly used for many communication industry ,Aprospace ,Auto Industry ,Communication,Indutrial Control ,Medical device ,Smart Home,consumer electronics ,automotive electronics , audio and video, optoelectronics, robotics, hydroelectric power, aerospace, education, power supply, printer ,Auto Industry ,Smart Home.etc.



ROHS OEM Multilayer Electronics Automotive PCBA 1OZ 2



Workshop



ROHS OEM Multilayer Electronics Automotive PCBA 1OZ 3

ROHS OEM Multilayer Electronics Automotive PCBA 1OZ 4ROHS OEM Multilayer Electronics Automotive PCBA 1OZ 5





Common packaging



1.PCB: Vacuum packaging with carton box
2.PCBA: ESD packaging with carton box



ROHS OEM Multilayer Electronics Automotive PCBA 1OZ 6





Company Brief Information



Haina lean Electronics Co., Ltd is a one-stop EMS supplier integrating PCB design, PCB manufacturing, Component sourcing and PCB assembly.

Here is strong component supply chain and procceurement team. Prototype and mass production are available. Competitive price is for high-quality and services. Exported to worldwide customer in US, Europe, Canada.
