  • High Light

    6OZ PCB SMT Assembly

    ,

    Electronic PCB SMT Assembly

    ,

    BGA rigid PCB assembly

  • Product Name
    PCB SMT Assembly
  • Material
    Fr4 High Tg; CEM-1; CEM-3
  • Copper Thickness
    1/3OZ Up To 6OZ
  • Min. Line Width
    0.030mm
  • Board Thickness
    Core Thickness 0.05mm-1.5mm ,Fineshed Board Thickness 0.3-3.5mm
  • Min. Hole Size
    Laser 0.05mm ; Mechnical 0.15
  • Surface Finishing
    HASL, ENIG, OSP, Lead Free HASL, HASL/OSP/ENIG
  • Service
    One-stop Service,PCB & PCBA,ODM And OEM
  • PCB Assembly Method
    Mixed; SMT, DIP, THT
  • Type
    PCB Assembly
  • MOQ
    1PC
  • Legond Color
    White
  • Place of Origin
    CHINA
  • Brand Name
    HNL-PCBA
  • Certification
    ISO9001,IS16949, ISO14001,ROHS ,UL, IPC-A ,QC080000
  • Model Number
    PCB Assembly 04
  • Minimum Order Quantity
    1 PC
  • Price
    Negotiable
  • Packaging Details
    ESD packaging with carton box
  • Delivery Time
    1-7days
  • Payment Terms
    T/T, Western Union, L/C, MoneyGram
  • Supply Ability
    10,000,000 Point /Day

Electronic Components PCB SMT Assembly , DIP BGA Rigid PCB Assembly

FR-4 HASL Pb-Free DIP BGA Electronic Components PCB SMT Assembly



PCB SMT Assembly Introduction



Haina Lean is an entity enterprise that specializes in electronic product design and development, supply chain management, PCBA and one-stop (OEM) production services for complete machine products. Also it owns profuse experience in manufacturing PCB,owned experienced technical R & D technology team, young and professional sales and customer service team, experienced and professional procurement team and assembly testing team, which make sure the products quality of the pass rate, on-time delivery rate of customer orders. Welcome to visit our factory!



PCBA CAPABILITIES



Layers 1 - 46 L
Substrate FR-4,CTI600,Tg180,,Anti CAF,Halogen-free,,High frequency,Tg170&HF
Max. panel size 700x610mm
Board thickness 0.3 mm - 3.5 mm.
Copper thickness 1/3 oz. to 6 oz. (outer) (Max)
Hole > 0.15mm.
Aspect Ratio 10 : 1
Min. track width 3.0 mils(partial)
Min. track space 3.0mils(partial)
Min. S/M bridge 3mil
Hole plugging diameter 0.3 mm~0.55 mm.
Impedance tolerance +/- 10%.
Color of S/M green,white,black,red,orange,yellow,blue,purple
Surface treatment OSP,HAL,HAL LF,ENIG,Hard gold,Imm Ag,Imm Sn,Peelable soldermask,Carbon ink print,Selective hard gold


PCB assembly process



Drilling--Exposure--Plating--Etaching & Stripping--Punching--Electrical Testing--SMT--Wave Soldering--Assembling--ICT--Function Testing--Temperature & Humidity Testing



Electronic Components PCB SMT Assembly , DIP BGA Rigid PCB Assembly 0



Our advantage



1.Service value

Independent quotation system to quickly serve the market

2.PCB manufacturing

High-tech PCB and PCB assembly production line

3.Material purchasing

A team of experienced electronic component procurement engineers

4.SMT post soldering

Dust-free workshop, high-end SMT patch processing



Electronic Components PCB SMT Assembly , DIP BGA Rigid PCB Assembly 1

Electronic Components PCB SMT Assembly , DIP BGA Rigid PCB Assembly 2



PCB SMT Assembly Delivery Time



Product Type Qty Normal lead time Quick-turn lead time
SMT+DIP 1-50 1WD-2WD 8H
SMT+DIP 51-200 2WD-3WD 1.5WD
SMT+DIP 201-2000 3WD-4WD 2WD
SMT+DIP ≥2001 4WD-5WD 3WD
PCBA(2-4Layer) 1-50 2.5WD-3.5WD 1WD
PCBA(2-4Layer) 51-2000 5WD-6WD 2.5WD
PCBA(2-4Layer) ≥2001 ≥7WD 5WD
PCBA(6-10Layer) 1-50 3WD-4WD 2.5WD
PCBA(6-10Layer) 51-2000 7WD-8WD 6WD
PCBA(10-HDILayer) 1-50 7WD-9WD 5WD
PCBA(10-HDILayer) 51-2000 9WD-11WD 7WD



Electronic Board Assembly Application Field



Our products are widely used in communication equipment, industrial control, consumer electronics, medical equipment, aerospace, light-emitting diode lighting, automotive electronics etc.



Electronic Components PCB SMT Assembly , DIP BGA Rigid PCB Assembly 3



Workshop



Electronic Components PCB SMT Assembly , DIP BGA Rigid PCB Assembly 4

Electronic Components PCB SMT Assembly , DIP BGA Rigid PCB Assembly 5Electronic Components PCB SMT Assembly , DIP BGA Rigid PCB Assembly 6





Common packaging



1.PCB: Vacuum packaging with carton box
2.PCBA: ESD packaging with carton box



Electronic Components PCB SMT Assembly , DIP BGA Rigid PCB Assembly 7



FAQ:



Q1:What service do you have?

A1: We provide turnkey solution including RD, PCB fabrication, SMT, final assembly,testing and other
value-added service.

Q2:What are the main products of your PCB/PCBA services?

A2:Our PCB/PCBA services are mainly for the industries including Medical, Automotive, Energy,
Metering/Measurements. Consumer Electronics.

Q3:How can we ensure our information should not let third party to see our design?

A3: We are wiling to sign NDA effect by customer side locallaw and promising to keep customers datain highconfidential level.

Q4:What does Parason need for a customized PCB order?

A4:When you place a PCB order, the customers need to provide Gerber or pcb file.If you do not have the fileinthe correct format, you can send all the details related to the products.

Q5:What will be needed for a customized PCBA order?

A5: When you place a PCBA order, you need to provide Gerber or pcb file and the BOM list to us.

Q6:Do you have an minimum order quantity?

A6:We accept order with as low as a quantity of 1 (piece or panel)



Company Brief Information



Haina lean Electronics Co., Ltd is a one-stop EMS supplier integrating PCB design, PCB manufacturing, Component sourcing and PCB assembly.

The company is specialized in electronic products supporting processing services, mainly to undertake circuit board design, layout production, components procurement, PCB plate making, circuit board welding assembly debugging and other OEM/ODM services.

Here is strong component supply chain and procceurement team. Prototype and mass production are available. Competitive price is for high-quality and services. Exported to worldwide customer in US, Europe, Canada.



Electronic Components PCB SMT Assembly , DIP BGA Rigid PCB Assembly 8
