Normal Tg Finger Gold PCB SMT Assembly , HASL Lead Free EMS PCBA

Normal Tg Finger Gold PCB SMT Assembly , HASL Lead Free EMS PCBA

  • High Light

    Normal Tg PCB SMT Assembly

    ,

    Finger Gold PCB SMT Assembly

    ,

    HASL Lead Free EMS PCBA

  • Product Name
    PCB SMT Assembly
  • Material
    Fr4 Normal Tg
  • Copper Thickness
    1/3OZ,1OZ, 2OZ, 3OZ, ...... 6OZ
  • Min. Line Width/spacing
    0.030mm/0.030mm
  • Board Thickness
    1.6mm, 2mm, ...... 3.5mm
  • Min. Hole Size
    Laser 0.05mm ; Mechnical 0.15
  • Surface Finishing
    HASL Lead Free
  • Solder Mask Color
    Blue.green Etc
  • Service
    One-stop Service,PCB&PCBA,ODM And OEM
  • Testing Service
    AOI, E-test, Function Test, Etc.
  • Number Of Layers
    2-layer, 4-layer, 6-layer, ......46 Layers
  • PCB Assembly Method
    Mixed, SMT, DIP, THT
  • Place of Origin
    CHINA
  • Brand Name
    HNL-PCBA
  • Certification
    ISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000
  • Model Number
    PCB Assembly 04
  • Minimum Order Quantity
    1 PC
  • Price
    Negotiable
  • Packaging Details
    ESD packaging with carton box
  • Delivery Time
    1-7days
  • Payment Terms
    T/T, Western Union, L/C, MoneyGram
  • Supply Ability
    10,000,000 Point /Day

Normal Tg Finger Gold PCB SMT Assembly , HASL Lead Free EMS PCBA

FR4 Normal Tg HASL Lead Free EMS FINGER GOLD PCB SMT Assembly



PCB SMT Assembly Introduction

We fabricate PCB Assembly with SMT,DIP, BGA, QFP, as well as THT selective soldering.Our engineers is qualified and experienced in producing surface-mount (SMT), through-hole (THT) and mixed-technology components and fine-pitch parts and ball grid arrays (BGAs) for high-density FR-4 PCBs .

We can produce and offer bulk volume printed circuit boards to meet your requirements. Although large volumes, each PCB goes through a strict testing process, ensuring that quality is never compromised. For high-volume PCBA order, we offer competitive pricing, as well as flexible shipment plans to you.



PCB CAPABILITIES





Layers 1 - 46 L (Custom )
Substrate FR-4,CTI600,Tg180,,Anti CAF,Halogen-free,,High frequency,Tg170&HF
Max. panel size 700x610mm (Custom)
Board thickness 0.3 mm - 3.5 mm.
Copper thickness 1/3 oz. to 6 oz. (outer) (Max)
Hole > 0.15mm.
Aspect Ratio 10 : 1
Min. track width 3.0 mils(partial)
Min. track space 3.0mils(partial)
Min. S/M bridge 3mil
Hole plugging diameter 0.3 mm~0.55 mm.
Impedance tolerance +/- 10%.
Color of S/M green,white,black,red,orange,yellow,blue,purple
Surface treatment OSP,HAL,HAL LF,ENIG,Hard gold,Imm Ag,Imm Sn,Peelable soldermask,Carbon ink print,Selective hard gold


PCBA CAPABILITIES



PCBA Capability
Material Type Item Min Max
PCB Dimension (length,width,height.mm) 50*40*0.38 600*400*4.2
Material FR-4,CEM-1,CEM-3,Aluminium-based board,Rogers,ceramic plate,FPC
Surface finish HASL,OSP,Immersion gold,Flash Gold Finger
Components Chip&IC 1005 55mm
BGA Pitch 0.3mm -
QFP Pitch 0.3mm -



Our SMT capabilities:



SMT Assembly: SMT provides a flexible high technology. These solutions include:

7 high-speed placement machines,

7 automatic printers with fiducial alignment,

2 X-ray machines,

BGA maintenance machines,

ICT test machines



Our DIP function:



A-8 semi-assembly production line with four wave soldering machines

1 U-shaped automatic assembly line for box-type building products with test stations

High temperature / low temperature aging test furnace B-4 for products required for aging test

With time control and temperature control

All products are 100% inspected and tested during the DIP process

Haina lean Electronics Co.,Ltd is a competitive China customize pcba for medical breathing machine OEM manufacturer, supplier and vendor, you can get quick turn customize pcba for medical breathing machine production prototypes and samples from our factory.

Hot Tags: customize pcba for medical breathing machine, China, supplier, manufacturer, factory, OEM manufacturer, vendor, samples, production, prototypes, quick turn



PCB SMT Assembly Process



1.Solder Paste stenciling---2.Surface Mount Technology (Pick and Place)---3.Reflow Soldering---4.Inspection and Quality Control---5.Through-Hole Component Insertion (DIP Process)---6.Final Inspection and Functional Test

Normal Tg Finger Gold PCB SMT Assembly , HASL Lead Free EMS PCBA 0



Our advantage



1.Service value

Independent quotation system to quickly serve the market

2.PCB manufacturing

High-tech PCB and PCB assembly production line

3.Material purchasing

A team of experienced electronic component procurement engineers

4.SMT post soldering

Dust-free workshop, high-end SMT patch processing



Normal Tg Finger Gold PCB SMT Assembly , HASL Lead Free EMS PCBA 1

Normal Tg Finger Gold PCB SMT Assembly , HASL Lead Free EMS PCBA 2



PCB SMT Assembly Delivery Time



Product Type Qty Normal lead time Quick-turn lead time
SMT+DIP 1-50 1WD-2WD 8H
SMT+DIP 51-200 2WD-3WD 1.5WD
SMT+DIP 201-2000 3WD-4WD 2WD
SMT+DIP ≥2001 4WD-5WD 3WD
PCBA(2-4Layer) 1-50 2.5WD-3.5WD 1WD
PCBA(2-4Layer) 51-2000 5WD-6WD 2.5WD
PCBA(2-4Layer) ≥2001 ≥7WD 5WD
PCBA(6-10Layer) 1-50 3WD-4WD 2.5WD
PCBA(6-10Layer) 51-2000 7WD-8WD 6WD
PCBA(10-HDILayer) 1-50 7WD-9WD 5WD
PCBA(10-HDILayer) 51-2000 9WD-11WD 7WD



PCB SMT Assembly Application Field



Our products are widely used in communication equipment, industrial control, consumer electronics, medical equipment, aerospace, light-emitting diode lighting, automotive electronics etc.



Normal Tg Finger Gold PCB SMT Assembly , HASL Lead Free EMS PCBA 3



Workshop



Normal Tg Finger Gold PCB SMT Assembly , HASL Lead Free EMS PCBA 4

Normal Tg Finger Gold PCB SMT Assembly , HASL Lead Free EMS PCBA 5Normal Tg Finger Gold PCB SMT Assembly , HASL Lead Free EMS PCBA 6



Common packaging



1.PCB: Vacuum packaging with carton box
2.PCBA: ESD packaging with carton box



Normal Tg Finger Gold PCB SMT Assembly , HASL Lead Free EMS PCBA 7



Partners



Normal Tg Finger Gold PCB SMT Assembly , HASL Lead Free EMS PCBA 8



Company Information



Haina lean Electronics Co., Ltd is a one-stop EMS supplier integrating PCB design, PCB manufacturing, Component sourcing and PCB assembly.

Our company was established in May 1, 2006 in Beijing. And expansion was completed in June 2016. The company is specialized in electronic products supporting processing services, mainly to undertake circuit board design, layout production, components procurement, PCB plate making, circuit board welding assembly debugging and other OEM/ODM services.



Our services

1.PCB Design & Layout                2.PCB Prototyping                   3.PCB Fabrication                          4.Turn Prototype PCB Assembly
5.PCB Assembly Service              6.Contract PCB Assembly       7.Trunkey PCB Assembly              8.Components sourcing,

9.Function test                            10.conformal coating                 11.complete assembly



Normal Tg Finger Gold PCB SMT Assembly , HASL Lead Free EMS PCBA 9
