FR4 Turnkey 4 Layer PCBA Prototype SMT Assembly service

FR4 Turnkey 4 Layer PCBA Prototype SMT Assembly service

  • High Light

    4 Layer prototype SMT assembly

    ,

    PCBA prototype SMT assembly service

    ,

    FR4 turnkey PCBA

  • Product Name
    PCBA Manufacturer
  • Material
    FR4
  • Copper Thickness
    0.3. 0.56 ..... 6oz
  • Max Board Size
    700x610mm
  • Min. Line Spacing
    0.030mm
  • Board Thickness
    0.3-3.5mm
  • Min. Line Width
    0.03mm
  • Min. Hole Size
    Laser 0.05mm ; Mechnical 0.15
  • Surface Finishing
    HASL,OSP,ENIG,HASL Lead Free,Immersion Gold
  • Solder Mask Color
    Blue.green.red.black.white.etc
  • PCBA Type
    Surface Mount, Thro-hole, Mixed Technology (SMT & Thru-hole), Single Or Double Sided Placement, Conformal Coating, Shield Cover Assembly For EMI Emission Control
  • Application
    Communication Equipment, Industrial Control, Consumer Electronics, Medical Equipment, Aerospace, Light-emitting Diode Lighting, Automotive Electronics
  • Service
    One-stop Service,PCB&PCBA,ODM And OEM
  • Pcb Assembly Method
    Mixed,BGA,SMT,Through-hole
  • HS Code
    8534009000
  • Certification
    RoHS, ISO9001, UL, SGS
  • Assembly Types
    Surface Mount, Thro-hole, Mixed Technology (SMT & Thru-hole), Single Or Double Sided Placement, Conformal Coating, Shield Cover Assembly For EMI Emission Control
  • Advantage
    Service Value,PCB Manufacturing,Material Purchasing,SMT Post Soldering
  • Place of Origin
    CHINA
  • Brand Name
    HNL-PCBA
  • Certification
    ISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000
  • Model Number
    PCBA-01
  • Minimum Order Quantity
    1 PC
  • Price
    Negotiable
  • Packaging Details
    ESD packaging with carton box
  • Delivery Time
    1-7days
  • Payment Terms
    T/T, Western Union, L/C, MoneyGram
  • Supply Ability
    10,000,000 Point /Day
